OEM#: 108265.00New OEM Original Outright

DC PERMANENT MAGNET MOTOR 7.5A 1-1/2 HP by Leeson

Your price:
$1,527.66 eachReady to ship
HomeLeeson10826500
DC PERMANENT MAGNET MOTOR 7.5A 1-1/2 HP by Leeson
DC PERMANENT MAGNET MOTOR 7.5A 1-1/2 HP by Leeson

OEM#: 108265.00
DC PERMANENT MAGNET MOTOR 7.5A 1-1/2 HP by Leeson

New OEM Original Outright
Your price:
$1,527.66 each
Ready to ship
Asset Information

A special handling fee may apply to this item. See FAQs for details.

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 108265.00 Key Specs
Item
DC PERMANENT MAGNET MOTOR 7.5A 1-1/2 HP
OEM
Leeson
OEM #
108265.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Ball
Body Diameter
5-5/8 in
Brush Type
Carbon
Country of Origin
USA
Frame
56C
Full Load Amps
7.5 A
Full Load Torque
37.8 in-lb
HP
1-1/2
Ins. Class
H
Length Less Shaft
13-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Design
DC Permanent Magnet
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Mounting Type
Face/Base
Motor Thermal Protection
None
Nameplate RPM
2500
Overall Length
15-5/16 in
Rotation
CW/CCW
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL (E49747), CSA (LR2025)
Voltage
180V DC
Voltage Compatibility
180V DC
