OEM#: 4468525

INFUSION PUMP ANALYZER by Fluke Electronics Corp (Biomedical Div.)

Ensure infusion pumps are tested accurately and quickly with real-time results using the IDA-1S one-channel infusion device analyzer, the newest member of the Fluke Biomedical IDA family. The IDA-1S is a portable, battery-operated instrument that allows for speedy verification of infusion device performance. The IDA-1S measures the flow rate and volume delivered, and the pressure generated in occlusions or blockages of the fluid line and is based on sophisticated measurement technology trusted by biomedical professionals around the world. It is easy to set up and requires little or no training to use. The IDA-1S can be used to test a wide variety of infusion pumps and the auto-start feature simplifies syringe pump testing and other tests that have long startup times.

Analyze the performance of a wide variety of infusion pumps quickly and accurately with the IDA-1S:

Get real-time results using the IDA-1S one-channel infusion device analyzer, a portable, battery-operated instrument that allows accurate and quick verification of infusion device performance. The IDA-1S measures the flow rate and volume delivered, and the pressure generated in occlusions or blockages of the fluid line and is based on sophisticated measurement technology trusted by biomedical professionals around the world. The IDA-1S infusion device analyzer is easy to set up and requires little or no training to use. It can be used to analyze a wide variety of infusion pumps and the auto-start feature simplifies syringe pump testing and other tests that have long startup times.

• Integrated carrying handle and lightweight for easy portability
• Battery provides up to 10 hours of continuous performance for on-the-go operation
• Compatible with a wide variety of infusion pumps
• Ensures maximum accuracy with Autostart mode enabling unit to begin testing only when fluid is detected
• Based on technology that is proven and trusted worldwide
• On-board memory allows test results storage instantly
• LCD touchscreen for ease of use
• Average and instantaneous flow measurement
• Occlusion pressure measurements to 45 psi
• Hydrograph graphical software to control unit, display results and print results via PC
• Global sales, service and support
• Storage of Results: Test results stored for later viewing, printing or transfer to PC. Typical practical capacity: 100 tests
• Power Down: The results of tests in progress will be saved in the case of accidental power down
• Computer Control: The Product can be fully controlled from a PC using Hydrograph V3 software for IDA-1S
• Battery Power: 4 x Panasonic HHR210AB NiMh 2000 mAh batteries
• Safety: IEC 61010-1: Overvoltage category II, Pollution Degree 2
• Electromagnetic Environment: IEC 61326-1: Basic
• Emissions Classification: IEC CISPR 11: Group 1, Class A
• Group 1 have intentionally generated and/or use conductively coupled radio-frequency energy which is necessary for the internal functioning of the equipment itself
• Class A equipment is suitable for use in nondomestic locations and/or directly connected to a low-voltage power supply network
• FCC: CFR47: Class A Part 15 subpart B
• Electromagnetic Compatibility: Applies to use in Korea only. Class A: Equipment (Industrial Broadcasting and Communication Equipment)

Flow Rate Measurement:

• Technique: Flow is calculated by measuring volume over time
• Range: 0.5 ml/h to 1000 ml/h
• Accuracy: 1 % of reading ± 1 LSD for flows of 16 ml/h to 200 ml/h for volumes over 20 ml, otherwise 2 % of reading ± 1 LSD for volumes over 10 ml under laboratory conditions
• Max test duration: 10 hours on battery

Volume Measurement:

• Technique: Volume measured directly by the measuring module in minimum sample sizes of 60 microliters
• Range: 0.06 ml to 999 ml
• Accuracy: 1 % of reading ± 1 LSD for flow rates of 16 ml/h to 200 ml/h for volumes over 20 ml. Otherwise 2 % of reading ± 1 LSD for volumes over 10 ml under laboratory conditions
• 10 hours on battery

Pressure Measurement:

• Technique: Direct measurement of pressure at the inlet port
• Range: 0 psi to 45 psi or equivalent in mmHg and kPa
• Accuracy: 11 % of full scale ± 1 LSD under laboratory conditions
• 30 minutes

Temperature:

• 15°C to 30°(59°to 86°F)
• -20°to +40°(-4°F to +104°F) when drained of all liquid

• Manufacturer: Fluke Electronics Corp (Biomedical Div.)
• Condition: New OEM Original
• Purchase Type: Outright
• Warranty: 12 Month
• Returnable: No

• Fluke Electronics Corp (Biomedical Div.)
  • IDA-5/1 US120V
  • IDA-1S
