Replaces Canon Medical Systems USA, Inc. E7252FX-ALNew Aftermarket Exchange
XH-180, 0.6X1.2, STATOR XS-AL, 150 KVP, 12°, 300KHU
Your price:
$5,755.62 each $7,100.00 Savings: $1,344.38 (19%)
BUYING OPTIONS:
New Aftermarket
Exchange PurchaseWarranty: Other (See Notes)
New Aftermarket
Outright Purchase
$6,676.20 eachWarranty: Other (See Notes)
Replaces Canon Medical Systems USA, Inc. E7252FX-ALXH-180, 0.6X1.2, STATOR XS-AL, 150 KVP, 12°, 300KHU
New Aftermarket
Exchange
ExchangeGoods sold on an "Exchange" basis require that Buyer return a like, repairable item within 15 days (or the seller's specified time frame) in order to receive the price quoted. For full details, see Terms and Conditions.
Your price:
$5,755.62 each
Assembly, X-Ray Tube Type, Rhenium-Tungsten Faced Molybdenum, 476mm Length, 74mm Diameter, 125kV Fluoroscopic Voltage, 150kV Radiographic Voltage, 12° Anode Angle, Natural or Forced Air Cooling Method, 0.6 x 1.2mm Focal Spot Size, 152.4mm Max. Diameter, 9700RPM Speed Rating, 300kHU Heat Capacity, 16 to 75°C Temperature Range
Asset Information
Warranty: 24M pro with the first 12M full
ADD TO LIST
Product Overview
High speed rotating anode X-ray tube assembly for high energy radiographic and cine-fluoroscopic operations. The heavy anode is constructed with specially processed rhenium-tungsten faced molybdenum target which is 74 mm diameter and has an improved coating to increase thermal emissivity.These tubes have foci 1.2 and 0.6, and are available for a maximum tube voltage 150 kV.Accommodated with IEC60526 type high-voltage cable receptacles.
Technical Specs
P/N: E7252FX-AL Key Specs
Item
XH-180, 0.6X1.2, STATOR XS-AL, 150 KVP, 12°, 300KHU
OEM
Canon Medical Systems USA, Inc.
OEM #
E7252FX-AL
Condition
New Aftermarket
Returnable
No
Warranty
Other (See Notes)
Angle
12 deg Target
Focal Spot
0.6/1.2
Heat Rating
300 KHU
Heat Units
300kHU
Horn Angle
90°
KW Rating
27/75
OEM Housing PN
XH-180
OEM Insert PN
E7252
Target Angle
12°
Equivalents
High speed rotating anode X-ray tube assembly for high energy radiographic and cine-fluoroscopic operations. The heavy anode is constructed with specially processed rhenium-tungsten faced molybdenum target which is 74 mm diameter and has an improved coating to increase thermal emissivity.These tubes have foci 1.2 and 0.6, and are available for a maximum tube voltage 150 kV.Accommodated with IEC60526 type high-voltage cable receptacles.
- E7252FX-AL: Toshiba America Medical Systems (TAMS): OEM Acquisition
