OEM#: WINL87-2/1-213/5TCNew OEM Original Outright
HELICAL INLINE SPEED REDUCER, 213/5TC INPUT FLANGE, 2:1 RATIO by Worldwide Electric Corporation
Your price:
$1,761.68 each
OEM#: WINL87-2/1-213/5TCHELICAL INLINE SPEED REDUCER, 213/5TC INPUT FLANGE, 2:1 RATIO by Worldwide Electric Corporation
New OEM Original Outright
Your price:
$1,761.68 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Worldwide Electric WINL87-2/1-213/5TC, Helical Inline Speed Reducer, 213/5TC Input Flange, 2:1 Ratio
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Technical Specs
P/N: WINL87-2/1-213/5TC Key Specs
Item
HELICAL INLINE SPEED REDUCER, 213/5TC INPUT FLANGE, 2:1 RATIO
OEM
Worldwide Electric Corporation
OEM #
WINL87-2/1-213/5TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Actual Gear Ratio
2.04
Box Size
87
Country of Origin
Taiwan
Cross Reference
SEW RX87
Gear Ratio
2:1
Gear Stages
1
Max Input Hp
26.27
Max Torque (In-Lbs.)
1859
Nema Frame
213/5TC
Output Speed (Rpm)
858
Overhung Load Lbs.
123
Worldwide Electric WINL87-2/1-213/5TC, Helical Inline Speed Reducer, 213/5TC Input Flange, 2:1 Ratio
