OEM#: WINL87-20/1-182/4TCNew OEM Original Outright
HELICAL INLINE SPEED REDUCER, 182/4TC INPUT FLANGE, 20:1 RATIO by Worldwide Electric Corporation
Your price:
$2,613.61 each
OEM#: WINL87-20/1-182/4TCHELICAL INLINE SPEED REDUCER, 182/4TC INPUT FLANGE, 20:1 RATIO by Worldwide Electric Corporation
New OEM Original Outright
Your price:
$2,613.61 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Worldwide Electric WINL87-20/1-182/4TC, Helical Inline Speed Reducer, 182/4TC Input Flange, 20:1 Ratio
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Technical Specs
P/N: WINL87-20/1-182/4TC Key Specs
Item
HELICAL INLINE SPEED REDUCER, 182/4TC INPUT FLANGE, 20:1 RATIO
OEM
Worldwide Electric Corporation
OEM #
WINL87-20/1-182/4TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Actual Gear Ratio
20.06
Box Size
87
Country of Origin
Taiwan
Cross Reference
SEW R87
Gear Ratio
20:1
Gear Stages
3
Max Input Hp
15.13
Max Torque (In-Lbs.)
9915
Nema Frame
182/4TC
Output Speed (Rpm)
87
Overhung Load Lbs.
2925
Worldwide Electric WINL87-20/1-182/4TC, Helical Inline Speed Reducer, 182/4TC Input Flange, 20:1 Ratio
