OEM#: WINL47-5/1-145TCNew OEM Original Outright
HELICAL INLINE SPEED REDUCER, 145TC INPUT FLANGE, 5:1 RATIO by Worldwide Electric Corporation
Your price:
$871.24 each
OEM#: WINL47-5/1-145TCHELICAL INLINE SPEED REDUCER, 145TC INPUT FLANGE, 5:1 RATIO by Worldwide Electric Corporation
New OEM Original Outright
Your price:
$871.24 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Worldwide Electric WINL47-5/1-145TC, Helical Inline Speed Reducer, 145TC Input Flange, 5:1 Ratio
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Technical Specs
P/N: WINL47-5/1-145TC Key Specs
Item
HELICAL INLINE SPEED REDUCER, 145TC INPUT FLANGE, 5:1 RATIO
OEM
Worldwide Electric Corporation
OEM #
WINL47-5/1-145TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Actual Gear Ratio
4.85
Box Size
47
Country of Origin
Taiwan
Cross Reference
SEW R47
Gear Ratio
5:1
Gear Stages
2
Max Input Hp
9.59
Max Torque (In-Lbs.)
1565
Nema Frame
145TC
Output Speed (Rpm)
361
Overhung Load Lbs.
440
Worldwide Electric WINL47-5/1-145TC, Helical Inline Speed Reducer, 145TC Input Flange, 5:1 Ratio
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
