OEM#: WINL97-3/1-254/6TCNew OEM Original Outright
HELICAL INLINE SPEED REDUCER, 254/6TC INPUT FLANGE, 3:1 RATIO by Worldwide Electric Corporation
Your price:
$2,997.27 each
OEM#: WINL97-3/1-254/6TCHELICAL INLINE SPEED REDUCER, 254/6TC INPUT FLANGE, 3:1 RATIO by Worldwide Electric Corporation
New OEM Original Outright
Your price:
$2,997.27 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Worldwide Electric WINL97-3/1-254/6TC, Helical Inline Speed Reducer, 254/6TC Input Flange, 3:1 Ratio
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Cast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratio's from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.
Technical Specs
P/N: WINL97-3/1-254/6TC Key Specs
Item
HELICAL INLINE SPEED REDUCER, 254/6TC INPUT FLANGE, 3:1 RATIO
OEM
Worldwide Electric Corporation
OEM #
WINL97-3/1-254/6TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Actual Gear Ratio
3.07
Box Size
97
Country of Origin
Taiwan
Cross Reference
SEW RX97
Gear Ratio
3:1
Gear Stages
1
Max Input Hp
38.23
Max Torque (In-Lbs.)
4071
Nema Frame
254/6TC
Output Speed (Rpm)
570
Overhung Load Lbs.
506
Worldwide Electric WINL97-3/1-254/6TC, Helical Inline Speed Reducer, 254/6TC Input Flange, 3:1 Ratio
