OEM#: PEWWE30-18-286TCNew OEM Original Outright

T-FRAME MOTOR, GP, TEFC, RIGID-C, 3 PH, 286TC, 36.4 FLA by Worldwide Electric Corporation

Your price:
$3,705.22 eachReady to ship
HomeWorldwide Electric CorporationPEWWE3018286TC
T-FRAME MOTOR, GP, TEFC, RIGID-C, 3 PH, 286TC, 36.4 FLA by Worldwide Electric Corporation
T-FRAME MOTOR, GP, TEFC, RIGID-C, 3 PH, 286TC, 36.4 FLA by Worldwide Electric Corporation

OEM#: PEWWE30-18-286TC
T-FRAME MOTOR, GP, TEFC, RIGID-C, 3 PH, 286TC, 36.4 FLA by Worldwide Electric Corporation

New OEM Original Outright
Your price:
$3,705.22 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Worldwide Electric T-Frame Motor PEWWE30-18-286TC, GP, TEFC, Rigid-C, 3 PH, 286TC, 36.4 FLAWorldwide Electric T-Frame Motor WWHT30-18-286TC, GP, TEFC, Rigid-C, 3 PH, 286TC, 36.4 FLA

Features

  • 1 - 300 HP
  • 3600, 1800 and 1200 RPM
  • 208-230/460 volt (1 - 200 HP)
  • 460 volt (250 - 300 HP)
  • TEFC enclosure
  • 1.15 service factor
  • Class F insulation
  • C-face - rigid base
  • EISA-Compliant - high efficiency
  • NEMA Design C - high torque (1 - 200 HP, 1800 and 1200 RPM)
  • Suitable for 50 Hz operation with 1.0 service factor (1 - 150 HP)
Technical Specs
P/N: PEWWE30-18-286TC Key Specs
Item
T-FRAME MOTOR, GP, TEFC, RIGID-C, 3 PH, 286TC, 36.4 FLA
OEM
Worldwide Electric Corporation
OEM #
PEWWE30-18-286TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Compliance
EISA
Country of Origin
China
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
80.4-72.8/36.4
Fl Efficiency
92.9
Frame
286TC
Horsepower
30
Is_Motor
Yes
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nameplate Rpm
1800
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Voltage
208-230/460
Weight
357
Worldwide Electric T-Frame Motor PEWWE30-18-286TC, GP, TEFC, Rigid-C, 3 PH, 286TC, 36.4 FLAWorldwide Electric T-Frame Motor WWHT30-18-286TC, GP, TEFC, Rigid-C, 3 PH, 286TC, 36.4 FLA
