OEM#: KHN37-5/1-H-143/5TCNew OEM Original Outright
CAST-IRON HELICAL BEVEL SPEED REDUCER, 143/5TC INPUT FLANGE, 5/1, FOOT MT by Worldwide Electric Corporation
Your price:
$1,982.64 each
OEM#: KHN37-5/1-H-143/5TCCAST-IRON HELICAL BEVEL SPEED REDUCER, 143/5TC INPUT FLANGE, 5/1, FOOT MT by Worldwide Electric Corporation
New OEM Original Outright
Your price:
$1,982.64 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
WWE KHN37-5/1-H-143/5TC, Cast-Iron Helical Bevel Speed Reducer; 143/5TC Input Flange, 5/1, Foot Mt
Cast-Iron, Helical Bevel Speed Reducers are available in box sizes 37-97 to support 1/4 HP to 30 HP NEMA frame motors in speed ratio's from 5:1 to 120:1. The units have NEMA motor quill style input flanges and standard hollow output bores, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation. Available in foot-mounted (KHN), torque arm mounted (KAN), or B5/B14 flange mounted (KAN) styles. Single shaft and double shaft output kits available.
Cast-Iron, Helical Bevel Speed Reducers are available in box sizes 37-97 to support 1/4 HP to 30 HP NEMA frame motors in speed ratio's from 5:1 to 120:1. The units have NEMA motor quill style input flanges and standard hollow output bores, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation. Available in foot-mounted (KHN), torque arm mounted (KAN), or B5/B14 flange mounted (KAN) styles. Single shaft and double shaft output kits available.
Technical Specs
P/N: KHN37-5/1-H-143/5TC Key Specs
Item
CAST-IRON HELICAL BEVEL SPEED REDUCER, 143/5TC INPUT FLANGE, 5/1, FOOT MT
OEM
Worldwide Electric Corporation
OEM #
KHN37-5/1-H-143/5TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Actual Gear Ratio
4.73:1
Box Size
37
Country of Origin
Taiwan
Cross Reference
SEW K37
Gear Ratio
5
Gear Stages
3
Max Input Hp
8.5
Max Torque (In-Lbs.)
1310
Nema Frame
143/5TC
Output Speed (Rpm)
370
Overhung Load Lbs.
375
WWE KHN37-5/1-H-143/5TC, Cast-Iron Helical Bevel Speed Reducer; 143/5TC Input Flange, 5/1, Foot Mt
Cast-Iron, Helical Bevel Speed Reducers are available in box sizes 37-97 to support 1/4 HP to 30 HP NEMA frame motors in speed ratio's from 5:1 to 120:1. The units have NEMA motor quill style input flanges and standard hollow output bores, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation. Available in foot-mounted (KHN), torque arm mounted (KAN), or B5/B14 flange mounted (KAN) styles. Single shaft and double shaft output kits available.
Cast-Iron, Helical Bevel Speed Reducers are available in box sizes 37-97 to support 1/4 HP to 30 HP NEMA frame motors in speed ratio's from 5:1 to 120:1. The units have NEMA motor quill style input flanges and standard hollow output bores, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation. Available in foot-mounted (KHN), torque arm mounted (KAN), or B5/B14 flange mounted (KAN) styles. Single shaft and double shaft output kits available.
