OEM#: E35MWNS 20:1 180TCNew OEM Original Outright

SPEED REDUCER C-FACE 180TC 20 1 by Winsmith

Your price:
$1,727.56 eachReady to ship
HomeWinsmithE35MWNS201180TC
SPEED REDUCER C-FACE 180TC 20 1 by Winsmith
SPEED REDUCER C-FACE 180TC 20 1 by Winsmith

OEM#: E35MWNS 20:1 180TC
SPEED REDUCER C-FACE 180TC 20 1 by Winsmith

New OEM Original Outright
Your price:
$1,727.56 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: E35MWNS 20:1 180TC Key Specs
Item
SPEED REDUCER C-FACE 180TC 20 1
OEM
Winsmith
OEM #
E35MWNS 20:1 180TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Dia.
1 1/8 in
Duty
Washdown
Finish
Epoxy Coating System
Frame
180TC
Gear Type
Worm
Housing Material
Cast Iron
Input RPM
1,725
Lubrication
Mobil Glygoyle(R) 460
Max. Input HP
5 hp
Max. Output Torque
3,334 in-lb
Mounting
Universal
Nominal Output RPM
86
Nominal Ratio
20:1
Number of Stages
1
Output Shaft Dia.
1 3/4 in
Output Shaft Height
4 in
Output Torque @ 2 HP
1,334 in-lb
Output Torque @ 3 HP
2,001 in-lb
Output Torque @ 5 HP
3,334 in-lb
Overhung Load
2,130 lb
Rotation
Reversible
Shaft Orientation
Right Angle
Single/Double Output/Universal
Double Output
Speed Reducer Type
C-Face
Worm Center Distance
3.5 in
