OEM#: E17MWNS 10:1 56C/140TCNew OEM Original Outright

SPEED REDUCER C-FACE 56C/140TC 10 1 by Winsmith

Your price:
$992.65 eachReady to ship
HomeWinsmithE17MWNS10156C140TC
SPEED REDUCER C-FACE 56C/140TC 10 1 by Winsmith
SPEED REDUCER C-FACE 56C/140TC 10 1 by Winsmith

OEM#: E17MWNS 10:1 56C/140TC
SPEED REDUCER C-FACE 56C/140TC 10 1 by Winsmith

New OEM Original Outright
Your price:
$992.65 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: E17MWNS 10:1 56C/140TC Key Specs
Item
SPEED REDUCER C-FACE 56C/140TC 10 1
OEM
Winsmith
OEM #
E17MWNS 10:1 56C/140TC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Dia.
7/8 in
Duty
Washdown
Finish
Epoxy Coating System
Frame
56C/140TC
Gear Type
Worm
Housing Material
Cast Iron
Input RPM
1,725
Lubrication
Mobil Glygoyle(R) 460
Max. Input HP
1.5 hp
Max. Output Torque
507 in-lb
Mounting
Universal
Nominal Output RPM
172
Nominal Ratio
10:1
Number of Stages
1
Output Shaft Dia.
1 in
Output Shaft Height
2 1/8 in
Output Torque @ 1 HP
338 in-lb
Output Torque @ 1.5 HP
507 in-lb
Output Torque @ 1/2 HP
169 in-lb
Output Torque @ 3/4 HP
253 in-lb
Overhung Load
650 lb
Rotation
Reversible
Shaft Orientation
Right Angle
Single/Double Output/Universal
Double Output
Speed Reducer Type
C-Face
Worm Center Distance
1.75 in
