OEM#: 1376N-01New OEM Original Outright

VACUUM PUMP 1 HP 1 PHASE 115/230V AC by Welch

Your price:
$9,978.53 eachReady to ship
HomeWelch1376N01
VACUUM PUMP 1 HP 1 PHASE 115/230V AC by Welch
VACUUM PUMP 1 HP 1 PHASE 115/230V AC by Welch

OEM#: 1376N-01
VACUUM PUMP 1 HP 1 PHASE 115/230V AC by Welch

New OEM Original Outright
Your price:
$9,978.53 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1376N-01 Key Specs
Item
VACUUM PUMP 1 HP 1 PHASE 115/230V AC
OEM
Welch
OEM #
1376N-01
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps AC
11.0/5.5
Application
Ammonia Chillers, Electrical Transformer Evacuation
Ballast
Yes
Displacement
10.6 cfm
End Vacuum
29.9 in Hg
Filter
No
Finish
Blue Metallic
HP
1 hp
Hz
60
Includes
Centering Ring Assembly, Conduit Wiring, Hinged Clamp, Hose Adapter, Synthetic Oil
Intake Male SAE Flare
ISO - NW 25
Max. dBA
60
Motor Type
ODP
Oil Capacity
80 oz
Outlet Size
1"-20
Overall Height
15 5/8 in
Overall Length
19 5/16 in
Overall Width
12 5/16 in
Phase
1
RPM
525 RPM
Tube Inside Dia.
13/16 in
Ultimate Pressure Torr
1 x 10-4
Valve Type
Bleed
Voltage
115/230
Weight
156 lb
