OEM#: 12536EG3G444TS-W22New OEM Original Outright
MOTOR 3-PHASE 125 HP RPM 3580 444/5TS by WEG
Your price:
$23,781.23 each
OEM#: 12536EG3G444TS-W22MOTOR 3-PHASE 125 HP RPM 3580 444/5TS by WEG
New OEM Original Outright
Your price:
$23,781.23 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 12536EG3G444TS-W22 Key Specs
Item
MOTOR 3-PHASE 125 HP RPM 3580 444/5TS
OEM
WEG
OEM #
12536EG3G444TS-W22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
CE, CSA, NOM, UL
CC Number
CC029A
Duty
Continuous
Frame
444/5TS
Full Load Amps
136
Horsepower
125 hp
Hz
60/50
Insulation Class
F
Length Less Shaft
36-1/2 in
Maximum Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3580
Nominal Efficiency
95.8 %
Number of Speeds
1
Overall Length
41-1/4 in
Phase
3
RPM Group
3001-3600
RPM Range
3001-3600
Shaft Diameter
2-3/8 in
Shaft Length
4-3/4 in
Voltage
230/460
