OEM#: 05012ES3EOW404T-W22New OEM Original Outright
MOTOR 50 HP 1 135 RPM 404T 208-230/460V by WEG
Your price:
$10,538.06 each
OEM#: 05012ES3EOW404T-W22MOTOR 50 HP 1 135 RPM 404T 208-230/460V by WEG
New OEM Original Outright
Your price:
$10,538.06 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 05012ES3EOW404T-W22 Key Specs
Item
MOTOR 50 HP 1 135 RPM 404T 208-230/460V
OEM
WEG
OEM #
05012ES3EOW404T-W22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
40 Degrees C
Base
Rigid
Duty
Continuous
Finish
White Epoxy
Frame
404T
Full Load Amps
137-124/62
HP
50
Hz
60
Ins. Class
F
Length Less Shaft
32-1/2 in
Motor Application
Pump
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Oil Well Pump
Motor Thermal Protection
None
Nameplate RPM
1135
Nominal Efficiency
88.1
Overall Length
39-3/4 in
Phase
3
Shaft Diameter
2-7/8 in
Shaft Length
7-1/4 in
Standards
CE, CSA Certified (LR38324), UL Recognized (E104590)
Voltage
208-230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
