OEM#: 03018ET3E286T-W22New OEM Original Outright
MTR 3 PH 30 HP 1765 230/460 EFF 93.6 by WEG
Your price:
$3,867.58 each
OEM#: 03018ET3E286T-W22MTR 3 PH 30 HP 1765 230/460 EFF 93.6 by WEG
New OEM Original Outright
Your price:
$3,867.58 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 03018ET3E286T-W22 Key Specs
Item
MTR 3 PH 30 HP 1765 230/460 EFF 93.6
OEM
WEG
OEM #
03018ET3E286T-W22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC029A
Duty
Continuous
Frame
286T
Full Load Amps
70.2/35.1
HP
30
Hz
60
Ins. Class
F
Length Less Shaft
23-5/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1765
Nominal Efficiency
93.6 %
Number of Speeds
1
Overall Length
27-15/16 in
Phase
3
Shaft Diameter
1-7/8 in
Shaft Length
4-5/8 in
Standards
CE, CSA, NOM, UL
Voltage
230/460
