OEM#: 02018ET3ECT256TF1-W2New OEM Original Outright
CT MOTOR 20 HP 1765 RPM 230/460V by WEG
Your price:
$4,080.63 each
OEM#: 02018ET3ECT256TF1-W2CT MOTOR 20 HP 1765 RPM 230/460V by WEG
New OEM Original Outright
Your price:
$4,080.63 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 02018ET3ECT256TF1-W2 Key Specs
Item
CT MOTOR 20 HP 1765 RPM 230/460V
OEM
WEG
OEM #
02018ET3ECT256TF1-W2
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
40 Degrees C
CC Number
CC029A
Duty
Continuous
Finish
Blue
Frame
256T
Full Load Amps
48.2/24.1
Green Certification or Other Recognition
NEMA Premium(R) Rated
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
HP
20
Hz
60/50
Includes
Space Heater
Ins. Class
F
Length Less Shaft
21 in
Motor Application
Cooling Tower
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1765
Nominal Efficiency
93.0%
Overall Length
1-5/8 in
Phase
3
Shaft Diameter
1-5/8 in
Shaft Length
4 in
Standards
CE, CSA Certified (LR38324), UL Recognized (E104590)
Voltage
230/460
