OEM#: 01012XT3E256TNew OEM Original Outright
HAZARDOUS LOC MTR 3 PH TEFC 10 HP T4 by WEG
Your price:
$3,405.85 each $3,436.27 Savings: $30.42 (1%)
OEM#: 01012XT3E256THAZARDOUS LOC MTR 3 PH TEFC 10 HP T4 by WEG
New OEM Original Outright
Your price:
$3,405.85 each
$3,436.27 Savings: $30.42 (1%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 01012XT3E256T Key Specs
Item
HAZARDOUS LOC MTR 3 PH TEFC 10 HP T4
OEM
WEG
OEM #
01012XT3E256T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
UL Listed (E87848), CSA Certified (LR50962)
CC Number
CC029A
Duty
Continuous
Frame
256T
Full Load Amps
29.4-26.6/13.3
Green Certification or Other Recognition
NEMA Premium(R) Rated
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Hazardous Location Class
1 C,D / 2 F,G
Horsepower
10
Hz
60
Insulation Class
F
Length Less Shaft
20 15/16 in
Maximum Ambient Temperature
40 Degrees C
Motor Application
Hazardous Location
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
T-Stat
NEMA Design
B
Nameplate RPM
1175
Nominal Efficiency
91 %
Overall Length
24-15/16 in
Phase
3
Shaft Diameter
1-5/8 in
Shaft Length
4 in
Temperature Code
T4
Voltage
208-230/460
