OEM#: 00236ET3E56-SNew OEM Original Outright
GENERAL PURPOSE MOTOR 2 HP 56H FRAME by WEG
Your price:
$775.45 each
OEM#: 00236ET3E56-SGENERAL PURPOSE MOTOR 2 HP 56H FRAME by WEG
New OEM Original Outright
Your price:
$775.45 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 00236ET3E56-S Key Specs
Item
GENERAL PURPOSE MOTOR 2 HP 56H FRAME
OEM
WEG
OEM #
00236ET3E56-S
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
CSA, UL
CC Number
CC029A
Duty
Continuous
Frame
56H
Full Load Amps
5.4-4.9/2.4
Horsepower
2
Hz
60/50
Includes
Conduit Box
Insulation Class
F
Inverter Rated
Yes
Length Less Shaft
12-1/16 in
Maximum Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3520
Nominal Efficiency
85.5 %
Number of Speeds
1
Overall Length
13-15/16 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Voltage
208-230/460
