OEM#: 033.4451.000New OEM Original Outright
314DW RAPID LOAD PUMP HEAD FOR 1.6MM WALL TUBING, 323 SERIES PERISTALTIC PUMPS by Watson Marlow
Your price:
$348.84 each
OEM#: 033.4451.000314DW RAPID LOAD PUMP HEAD FOR 1.6MM WALL TUBING, 323 SERIES PERISTALTIC PUMPS by Watson Marlow
New OEM Original Outright
Your price:
$348.84 each
Pump Head, Rapid Load Type, 0.5, 0.8, 1.6, 3.2, 4.8, 6.4, 8mm Compatible Tubing Bore Size, 1200mL/min Flow Rate (Continuous), 2400mL/min Flow Rate (Intermittent), 4 Number of Rollers, 400RPM Speed Range, For 1.6mm Wall Tubing, 323 Series Peristaltic Pumps
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The 300 series combines performance, practicality and design. With its iconic flip-top design it is an industry standard OEM product in medical device, biotechnology and diagnostic applications, and very popular in many other applications too. Available as pumpheads only for customers wishing to specify their own motor/control. In three, four, six and eight roller versions. More rollers for greater accuracy and reduced pulsation. The three-roller 313 pumphead offers maximum flows. Great flexibility with nine tubing sizes in many different tubing materials. Providing flows to 2 L/min continuously or 3 L/min intermittently. Strong IXEF moulded pumpheads available in a range of colours.Its iconic flip-top design for fast and error-free tube loading makes it the most popular choice in many medical and upstream cell culture applications Pumpheads can be extended to provide up to six separate channels depending on drive torque Three and four roller versions are most popular. Up to eight rollers is possible for lowest pulsation and greatest accuracy
Features
- Its iconic flip-top design for fast and error-free tube loading makes it the most popular choice in many medical and upstream cell culture applications
- Pumpheads can be extended to provide up to six separate channels depending on drive torque
- Three and four roller versions are most popular. Up to eight rollers is possible for lowest pulsation and greatest accuracy
Technical Specs
P/N: 033.4451.000 Key Specs
Item
314DW RAPID LOAD PUMP HEAD FOR 1.6MM WALL TUBING, 323 SERIES PERISTALTIC PUMPS
OEM
Watson Marlow
OEM #
033.4451.000
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Compatible Tubing Bore Size
0.5, 0.8, 1.6, 3.2, 4.8, 6.4, 8mm
Flow Rate (Continuous)
1200mL/min
Flow Rate (Intermittent)
2400mL/min
For Use With
For 1.6mm Wall Tubing, 323 Series Peristaltic Pumps
Number of Rollers
4
Speed Range
400RPM
Type
Rapid Load
The 300 series combines performance, practicality and design. With its iconic flip-top design it is an industry standard OEM product in medical device, biotechnology and diagnostic applications, and very popular in many other applications too. Available as pumpheads only for customers wishing to specify their own motor/control. In three, four, six and eight roller versions. More rollers for greater accuracy and reduced pulsation. The three-roller 313 pumphead offers maximum flows. Great flexibility with nine tubing sizes in many different tubing materials. Providing flows to 2 L/min continuously or 3 L/min intermittently. Strong IXEF moulded pumpheads available in a range of colours.Its iconic flip-top design for fast and error-free tube loading makes it the most popular choice in many medical and upstream cell culture applications Pumpheads can be extended to provide up to six separate channels depending on drive torque Three and four roller versions are most popular. Up to eight rollers is possible for lowest pulsation and greatest accuracy
