OEM#: SD9368-EHLNew OEM Original Outright
VIVOTEK S SERIES SD9368-EHL, NETWORK SURVEILLANCE CAMERA, DOME by VIVOTEK Inc.
Your price:
$2,815.90 each $3,128.00 Savings: $312.10 (10%)
OEM#: SD9368-EHLVIVOTEK S SERIES SD9368-EHL, NETWORK SURVEILLANCE CAMERA, DOME by VIVOTEK Inc.
New OEM Original Outright
Your price:
$2,815.90 each
$3,128.00 Savings: $312.10 (10%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The VIVOTEK SD9368-EHL is a professional IR speed dome camera (PTZ) with 2MP resolution at 60 fps, excellent for video surveillance in wide coverage areas such as airports, city surveillance, and manufacturing facilities. SD9368-EHL is equipped with 250M IR illuminators and a 40x optical zoom to gain more details in any scene. The smart IR technology allows broad coverage FOV and highly uniform IR intensity while at the same time avoiding hotspots.
Video surveillance in big areas has the potential for many incidents, SD9368-EHL's built-in Smart Tracking Advanced allows user to identify the risk and track the suspected person automatically in real time.
SD9368-EHL's camera body is protected with IP66, IK10 and NEMA 4x certifications against rain, dust, and corrosion. It also supports a wide operating temperature from -40? to 60? (-40°F to 140°F) for operation in extreme weather conditions.
Video surveillance in big areas has the potential for many incidents, SD9368-EHL's built-in Smart Tracking Advanced allows user to identify the risk and track the suspected person automatically in real time.
SD9368-EHL's camera body is protected with IP66, IK10 and NEMA 4x certifications against rain, dust, and corrosion. It also supports a wide operating temperature from -40? to 60? (-40°F to 140°F) for operation in extreme weather conditions.
- 40x optical zoom, auto focus
- 360° continuous pan, -20° to 90° (auto flip) tilt
- 250M IR with Smart IR
- Weather-proof IP66-rated, Vandal-proof IK10 and NEMA 4x-rated housing
- -40°C - 60°C Wide Temperature Range for extreme weather conditions
- EIS (Electronic Image Stabilization) for image stability
- Trend Micro IoT security
Technical Specs
P/N: SD9368-EHL Key Specs
Item
VIVOTEK S SERIES SD9368-EHL, NETWORK SURVEILLANCE CAMERA, DOME
OEM
VIVOTEK Inc.
OEM #
SD9368-EHL
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Audio
Yes: two-way audio capability
Camera
Color - Day&Night
Camera Mount Type
Wall mount
Connectivity Technology
Wired
Country of Origin
Taiwan
Device Type
Network surveillance camera - pan / tilt / zoom - dome - vandal / weatherproof
Dimensions (W x D x H)
10.1 in x 10.1 in x 13.2 in
Focal Length
4.25 mm - 170 mm
Focal Length Control
Motorized zoom
Focus Adjustment
Automatic, motorized
Interfaces
Ethernet 10Base-T/100Base-TX
Lens Iris
F/1.6-4.95 - auto iris (DC)
Maximum Frame Rate
60 frames per second
Maximum Resolution
1920 x 1080
Minimum Illumination
0.04 lux - color - F1.6 - 0.005 lux - B&W - F1.6
Motion Detection
Yes
Operating Environmental Parameters
-40 °F - 140 °F; 98% RH (non-condensing) relative humidity
Optical Sensor Type
PS CMOS - 1/2.8" - 2 MP
Optical Zoom
40 x
Panning Range (degrees)
360
Tilting Range (degrees)
-20 to +90
Video Modes
1080p
Voltage
DC 48 V / AC 24 V / PoE++ Class 6
Weight
15.65 lbs
The VIVOTEK SD9368-EHL is a professional IR speed dome camera (PTZ) with 2MP resolution at 60 fps, excellent for video surveillance in wide coverage areas such as airports, city surveillance, and manufacturing facilities. SD9368-EHL is equipped with 250M IR illuminators and a 40x optical zoom to gain more details in any scene. The smart IR technology allows broad coverage FOV and highly uniform IR intensity while at the same time avoiding hotspots.
Video surveillance in big areas has the potential for many incidents, SD9368-EHL's built-in Smart Tracking Advanced allows user to identify the risk and track the suspected person automatically in real time.
SD9368-EHL's camera body is protected with IP66, IK10 and NEMA 4x certifications against rain, dust, and corrosion. It also supports a wide operating temperature from -40? to 60? (-40°F to 140°F) for operation in extreme weather conditions.
Video surveillance in big areas has the potential for many incidents, SD9368-EHL's built-in Smart Tracking Advanced allows user to identify the risk and track the suspected person automatically in real time.
SD9368-EHL's camera body is protected with IP66, IK10 and NEMA 4x certifications against rain, dust, and corrosion. It also supports a wide operating temperature from -40? to 60? (-40°F to 140°F) for operation in extreme weather conditions.
- 40x optical zoom, auto focus
- 360° continuous pan, -20° to 90° (auto flip) tilt
- 250M IR with Smart IR
- Weather-proof IP66-rated, Vandal-proof IK10 and NEMA 4x-rated housing
- -40°C - 60°C Wide Temperature Range for extreme weather conditions
- EIS (Electronic Image Stabilization) for image stability
- Trend Micro IoT security
