OEM#: U2P3DNew OEM Original Outright
MTR 3PH 2HP 1200RPM 208-230/460 EFF 88.5 by Usem
Your price:
$1,004.48 each
OEM#: U2P3DMTR 3PH 2HP 1200RPM 208-230/460 EFF 88.5 by Usem
New OEM Original Outright
Your price:
$1,004.48 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: U2P3D Key Specs
Item
MTR 3PH 2HP 1200RPM 208-230/460 EFF 88.5
OEM
Usem
OEM #
U2P3D
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC030A
Country of Origin
Mexico
Duty
Continuous
Frame
184T
Full Load Amps
6.4-6.2/3.1
Green Certification or Other Recognition
NEMA Premium(R) Rated
HP
2 hp
Hz
60/50
Ins. Class
F
Length Less Shaft
13-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Aluminum
Motor Mounting Position
Horizontal or Vertical Shaft Down
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1200
Nominal Efficiency
88.5 %
Number of Speeds
1
Overall Length
16-1/4 in
Phase
3
RPM Group
1101-1200
RPM Range
1101-1200
Shaft Diameter
1-1/8 in
Shaft Length
2-3/4 in
Standards
CE, CSA, UL
Voltage
208-230/460
