OEM#: U10P1DCRNew OEM Original Outright
GP MOTOR 3-PHASE TEFC 10HP 60/50HZ by Usem
Your price:
$1,981.22 each
OEM#: U10P1DCRGP MOTOR 3-PHASE TEFC 10HP 60/50HZ by Usem
New OEM Original Outright
Your price:
$1,981.22 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: U10P1DCR Key Specs
Item
GP MOTOR 3-PHASE TEFC 10HP 60/50HZ
OEM
Usem
OEM #
U10P1DCR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC030A
Country of Origin
Mexico
Duty
Continuous
Frame
215TC
Full Load Amps
26.4-23.5/11.8
Green Certification or Other Recognition
NEMA Premium(R) Rated
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
HP
10 hp
Hz
60/50
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
17 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Aluminum
Motor Mounting Position
Horizontal
Motor Mounting Type
Face
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3520
Nominal Efficiency
90.2 %
Number of Speeds
1
Overall Length
20-1/8 in
Phase
3
RPM Group
3001-3600
RPM Range
3001-3600
Shaft Diameter
1-3/8 in
Shaft Length
3-1/8 in
Standards
CE, CSA (191252), NP, UL (E51488)
Voltage
208-230/460
