OEM#: PDU40TDUALNew OEM Original Outright
PDU BASIC DUAL CIRCUIT 120V 20A 5-15/20R 40 OUTLET L5-20P 0URM by Tripp Lite
Your price:
$360.28 each $551.88 Savings: $191.60 (35%)
View All
OEM#: PDU40TDUALPDU BASIC DUAL CIRCUIT 120V 20A 5-15/20R 40 OUTLET L5-20P 0URM by Tripp Lite
New OEM Original Outright
Your price:
$360.28 each
$551.88 Savings: $191.60 (35%)
3.8kW Single-Phase Dual-Circuit 120V Basic PDU, 40 NEMA 5-15/20R Outlets, NEMA L5-20P/5-20P Inputs, 10 ft. Cords, 0U
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDU40TDUAL 3.8kW Single-Phase Dual-Circuit 120V Basic PDU works as two independent PDUs in a single housing, perfect for networking, telecom, security, audio/video and sound reinforcement applications. Ideal for high-density network equipment with dual redundant input cables, it features 40 NEMA 5-15/20R outlets split evenly into two separate power circuits. Each power circuit, including its input plug, power cord, breaker and outlets, is color-coded black or gray for easy identification. Both 10-foot power cords feature NEMA L5-20P input plugs and come with optional adapters to convert them to NEMA 5-20P plugs, which are not color-coded. Connect the plugs to separate mains input power sources, generators or protected UPS systems to distribute AC power to connected equipment.The switchless design prevents an accidental shutdown, which could lead to costly downtime. Dual 20A circuit breakers protect connected equipment from dangerous overloads. The 70-inch all-metal housing supports toolless 0U vertical mounting in EIA-standard 19-inch racks, as well as on a wall or workbench or under a counter with user-supplied hardware.
- Package Includes:
• PDU40TDUAL 3.8kW Single-Phase Dual-Circuit 120V Basic PDU
• (2) NEMA L5-20P to NEMA 5-20P Plug Set Adapters
• Mounting Hardware
• Owner’s Manual
Features
- 40 NEMA 5-15/20R outlets in 2 separate circuits
- Dual NEMA L5-20P/5-20P inputs with 10 ft. (3 m) cords
- Functions as 2 independent 20A PDUs in one housing
- Supports toolless 0U vertical button-mounting
- Switchless design prevents accidental shutdown
Technical Specs
P/N: PDU40TDUAL Key Specs
Item
PDU BASIC DUAL CIRCUIT 120V 20A 5-15/20R 40 OUTLET L5-20P 0URM
OEM
Tripp Lite
OEM #
PDU40TDUAL
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Input Connectors
2 x power NEMA L5-20
Input Voltage
AC 120 V
Output connectors
40 x power NEMA 5-15R/20R
Power Capacity
3.8 kW
The PDU40TDUAL 3.8kW Single-Phase Dual-Circuit 120V Basic PDU works as two independent PDUs in a single housing, perfect for networking, telecom, security, audio/video and sound reinforcement applications. Ideal for high-density network equipment with dual redundant input cables, it features 40 NEMA 5-15/20R outlets split evenly into two separate power circuits. Each power circuit, including its input plug, power cord, breaker and outlets, is color-coded black or gray for easy identification. Both 10-foot power cords feature NEMA L5-20P input plugs and come with optional adapters to convert them to NEMA 5-20P plugs, which are not color-coded. Connect the plugs to separate mains input power sources, generators or protected UPS systems to distribute AC power to connected equipment.The switchless design prevents an accidental shutdown, which could lead to costly downtime. Dual 20A circuit breakers protect connected equipment from dangerous overloads. The 70-inch all-metal housing supports toolless 0U vertical mounting in EIA-standard 19-inch racks, as well as on a wall or workbench or under a counter with user-supplied hardware.
