OEM#: PDU3V602D354BNew OEM Original Outright
PDU 3-PHASE VERTICAL STRIP ATS 208V 17.3KW 48 C13, 6 C19 0URM by Tripp Lite
Your price:
$1,179.23 each $1,380.00 Savings: $200.77 (15%)
View All
OEM#: PDU3V602D354BPDU 3-PHASE VERTICAL STRIP ATS 208V 17.3KW 48 C13, 6 C19 0URM by Tripp Lite
New OEM Original Outright
Your price:
$1,179.23 each
$1,380.00 Savings: $200.77 (15%)
17.3kW 3-Phase Vertical PDU Strip, 208V Outlets (48 C13 & 6 C19), 0U Rack-Mount, Accessory for Select ATS PDUs
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDU3V602D354B 17.3kW 3-Phase Vertical PDU Outlet Strip is a required accessory option for Tripp Lite’s PDU360AT6G60 and other 3-phase ATS PDUs that specify compatibility with this model. It’s recommended for high-density equipment racks in data centers and server rooms.When used with Tripp Lite’s PDU360AT6G60, the PDU3V602D354B supports up to 17.3kW total output with 27.8A balanced maximum full load per output phase combination (L1–L2, L2–L3, L3–L1) and 13.9A balanced maximum per breakered output load bank (C1–C6).The 48 C13 and six C19 single-phase 208V outlets are interlaced to help you balance loads by spreading connections across the phase combinations throughout the rack. Each outlet is numbered and color-coded to help you keep track of connected devices and which phase combination powers each. Dual 2.5-foot power cords, each with a special seven-position input plug, connect directly to the ATS’s rear receptacles. The PDU3V602D354B’s rugged all-metal housing mounts vertically in an EIA-standard 19-inch rack with no tools needed. Vertical 0U installation reduces cord clutter and improves airflow through the rack.
- Package Includes:
• PDU3V602D354B 17.3kW 3-Phase Vertical PDU Outlet Strip, 48 C13 & 6 C19 Outlets
Features
- 54 single-phase 208V outlets (48 C13 & 6 C19)
- Required for select Tripp Lite 3-phase ATS PDUs
- Simplifies load balancing with interlaced color-coded outlets
- Supports 0U toolless vertical rack mounting
- Supports up to 17.3kW total output
Technical Specs
P/N: PDU3V602D354B Key Specs
Item
PDU 3-PHASE VERTICAL STRIP ATS 208V 17.3KW 48 C13, 6 C19 0URM
OEM
Tripp Lite
OEM #
PDU3V602D354B
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Cord Length
29.9 in
Dimensions (WxDxH)
4 in x 2.2 in x 70 in
Input Connectors
2
Input Voltage
AC 200/208/220/230/240 V
Input Wiring
3-phase
Output Voltage
AC 200/208/220/230/240 V
Output connectors
42 x power IEC 60320 C13 - 208 V - 12 A - 12 x power IEC 60320 C19 - 208 V - 16 A
Power Capacity
17.3 kW
Rack Size
0U
Weight
19 lbs
The PDU3V602D354B 17.3kW 3-Phase Vertical PDU Outlet Strip is a required accessory option for Tripp Lite’s PDU360AT6G60 and other 3-phase ATS PDUs that specify compatibility with this model. It’s recommended for high-density equipment racks in data centers and server rooms.When used with Tripp Lite’s PDU360AT6G60, the PDU3V602D354B supports up to 17.3kW total output with 27.8A balanced maximum full load per output phase combination (L1–L2, L2–L3, L3–L1) and 13.9A balanced maximum per breakered output load bank (C1–C6).The 48 C13 and six C19 single-phase 208V outlets are interlaced to help you balance loads by spreading connections across the phase combinations throughout the rack. Each outlet is numbered and color-coded to help you keep track of connected devices and which phase combination powers each. Dual 2.5-foot power cords, each with a special seven-position input plug, connect directly to the ATS’s rear receptacles. The PDU3V602D354B’s rugged all-metal housing mounts vertically in an EIA-standard 19-inch rack with no tools needed. Vertical 0U installation reduces cord clutter and improves airflow through the rack.
- Package Includes:
• PDU3V602D354B 17.3kW 3-Phase Vertical PDU Outlet Strip, 48 C13 & 6 C19 Outlets
