OEM#: N784-001-SC-MMNew OEM Original Outright

10/100 UTP TO MULTIMODE FIBER 850NM MEDIA CONVERTER RJ45 / SC by Tripp Lite

Your price:
$88.34 each
$121.55 Savings: $33.21 (27%)
Ready to ship
HomeTripp Liten784001scmm
10/100 UTP TO MULTIMODE FIBER 850NM MEDIA CONVERTER RJ45 / SC by Tripp Lite
10/100 UTP TO MULTIMODE FIBER 850NM MEDIA CONVERTER RJ45 / SC by Tripp Lite

OEM#: N784-001-SC-MM
10/100 UTP TO MULTIMODE FIBER 850NM MEDIA CONVERTER RJ45 / SC by Tripp Lite

New OEM Original Outright
Your price:
$88.34 each
$121.55 Savings: $33.21 (27%)

10/100 SC Multimode Media Converter, 550M, 850nm

Ready to ship
Asset Information

1-Year Limited Warranty

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Tripp Lite's N784-001-SC-MM 10/100 to Multimode Media Converter ( RJ45 to SC ) is an economical way to extend the distance of network nodes up to 550 Meters by converting Cat5e UTP cables to Multimode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration, and the UTP port senses the network speed automatically. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.

    System Requirements:
    • 10/100 Ethernet Network
    • Multimode SC Fiber cable


    Package Includes:
    • 10/100 SC Multimode Media Converter, 550M, 850nm
    • External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz; 5V, 1.2A)
    • User Manual
Features
  • Auto detects Full/Half Duplex Transfer Mode
  • Extends a 100Mb Ethernet signal up to 550M over Multimode Fiber Optic Cable
  • Supports Multimode 50/125 cable up to 2KM or 62.5/125 cable up to 550M
Technical Specs
P/N: N784-001-SC-MM Key Specs
Item
10/100 UTP TO MULTIMODE FIBER 850NM MEDIA CONVERTER RJ45 / SC
OEM
Tripp Lite
OEM #
N784-001-SC-MM
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Cabling Type
10Base-T, 100Base-TX
Data Link Protocol
10Mb LAN, 100Mb LAN
Data Transfer Rate
100 Mbps
Dimensions (WxDxH)
4.7 in x 2.8 in x 1 in
Form Factor
External
Max Transfer Distance
1800 ft
Optical Wave Length
850 nm
Power
AC 120/230 V
Weight
16.01 oz
Tripp Lite's N784-001-SC-MM 10/100 to Multimode Media Converter ( RJ45 to SC ) is an economical way to extend the distance of network nodes up to 550 Meters by converting Cat5e UTP cables to Multimode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration, and the UTP port senses the network speed automatically. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.

    System Requirements:
    • 10/100 Ethernet Network
    • Multimode SC Fiber cable


    Package Includes:
    • 10/100 SC Multimode Media Converter, 550M, 850nm
    • External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz; 5V, 1.2A)
    • User Manual
