OEM#: B004-DPUA2-K

DISPLAYPORT KVM SWITCH 2-PORT W AUDIO, CABLES & USB 3.0 HUB by Tripp Lite

The desktop B004-DPUA2-K 2-Port DisplayPort KVM Switch lets you access, control, boot and reboot two DisplayPort computers using one DisplayPort monitor, USB keyboard and USB mouse. Switching between DisplayPort computers is quick and simple using keyboard hotkeys or buttons on the unit. You can also plug microphones and speakers into the 3.5 mm mini-stereo jacks, and the two-port USB 3.0 SuperSpeed hub allows you to connect peripherals, such as a webcam, flash drive, printer or scanner, and share them with both computers. Because the audio and USB 3.0 hub ports can be accessed independently, you can, for instance, use a printer connected to the hub to print data from one computer while also listening to music from the other computer.All necessary cables are included. The B004-DPUA2-K supports digital video resolutions up to 2560 x 1600 (including 1080p), 2-channel stereo audio and data transfer rates up to 5 Gbps. The monitor’s EDID information is sent to the connected computer when selected.The B004-DPUA2-K is easy to set up with no software to install and supports Windows, Mac, Linux and Sun. The USB 3.0 hub is backward-compatible with USB 2.0 and USB 1.1 devices.

System Requirements:
• DisplayPort-enabled monitor
• USB keyboard and mouse
• Speaker and microphone with 3.5 mmmini-stereo plugs (for audio)
• Computer with USB port (need USB3.0 port for USB 3.0 speeds)
• Computer with 3.5 mm mini-stereo jacks(for audio)
• Compatible with all major operatingsystems

Package Includes:
• B004-DPUA2-K 2-Port DisplayPort KVM Switch
• (2) DisplayPort cables, 4 ft.
• (2) USB 3.0 Type-A to Type-B cables, 4 ft.
• (2) 3.5 mm mini-stereo cables, 4 ft.
• External power supply (Input: 100/240V, 50/60 Hz, 0.5A; Output: 9V, 2A)
• Universal plug adapters (NEMA 1-15P, CEE 7/16, BS1363, and AS3112)
• Owner’s manual
