OEM#: SV80KM4P4BNew OEM Original Outright
80KVA SMART ONLINE 3-PHASE UPS MEDIUM FRAME MODULAR 4 BATTERIES by Tripp Lite
0
View All
OEM#: SV80KM4P4B80KVA SMART ONLINE 3-PHASE UPS MEDIUM FRAME MODULAR 4 BATTERIES by Tripp Lite
New OEM Original Outright
SmartOnline SV Series 80kVA Medium-Frame Modular Scalable 3-Phase On-Line Double-Conversion 208/120V 50/60Hz UPS System, 4 Battery Modules
Asset Information
2-Year Limited Warranty
ADD TO LIST
Product Overview
The SV80KM4P4B SmartOnline® SV Series 80kVA 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system is ideal for protecting a variety of critical IT systems.The SV80KM4P4B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), four 20kVA SV20PM power modules and four SVBM battery modules. It comes fully configured for 80kVA total capacity or 60kVA with enhanced N+1 protection. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.With up to 92% efficiency in standard mode and up to 99% efficiency in optional economy mode, this 80kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.
- Package Includes:
• SV80KM4P4B SmartOnline SV Series 80kVA 3-Phase On-Line Double-Conversion UPS System
• Pre-installed WEBCARDLX network interface
• (4) SV20PM 20kVA power modules
• (4) SVBM battery modules
• Owner’s manual
Features
- DSP/IGBT technology and 1% output voltage regulation
- Economy mode option helps reduce operating and cooling costs
- Fully configured for 80kVA capacity or 60kVA w/N+1 fault tolerance
- Includes 4 internal batteries, supports extra external batteries
- Pre-installed WEBCARDLX network interface for 24/7 remote access
Technical Specs
P/N: SV80KM4P4B Key Specs
Item
80KVA SMART ONLINE 3-PHASE UPS MEDIUM FRAME MODULAR 4 BATTERIES
OEM
Tripp Lite
OEM #
SV80KM4P4B
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Batteries Qty
4
Battery
Expandable
Dimensions (WxDxH)
23.6 in x 43.3 in x 79.1 in
Input Connectors
Hardwire
Input Voltage
AC 120/127/208/220 V
Input Wiring
3-phase WYE (star)
Networking
RS-232
Output Voltage
AC 120/127/208/220 V
Output connectors
Hardwire
Power Capacity
72 kW / 80000 VA
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Run Time (Up To)
4 min
Weight
1826.97 lbs
