OEM#: SV20KS1P3BNew OEM Original Outright
20KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES by Tripp Lite
Your price:
$38,022.01 each $44,493.00 Savings: $6,470.99 (15%)
View All
OEM#: SV20KS1P3B20KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES by Tripp Lite
New OEM Original Outright
Your price:
$38,022.01 each
$44,493.00 Savings: $6,470.99 (15%)
SmartOnline SV Series 20kVA Small-Frame Modular Scalable 3-Phase On-Line Double-Conversion 208/120V 50/60 Hz UPS System, 3 Battery Modules
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The SV20KS1P3B SmartOnline® SV Series 20kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system with a high 0.9 power factor is ideal for protecting a variety of critical IT systems.The SV20KS1P3B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS), one 20kVA SV20PM power module and three SVBM battery modules. Space is included for up to two additional user-installable SV20PM power modules. External ±120VDC battery options, such as BP240V370, are also available from Tripp Lite for even more extended runtime.The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.With up to 92% efficiency in standard mode and up to 98% efficiency in optional economy mode, this 20kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting.
- Package Includes:
• SV20KS1P3B SmartOnline SV Series 20kVA Small-Frame 3-Phase On-Line Double-Conversion UPS System
• Pre-installed WEBCARDLX network interface
• (1) SV20PM 20kVA power module
• (3) SVBM battery modules
• Owner’s manual
Features
- DSP/IGBT technology and 1% output voltage regulation
- Economy mode option helps reduce operating and cooling costs
- Includes 3 internal battery modules, external options available
- Pre-installed WEBCARDLX network interface for 24/7 remote access
- Scalable capacity up to 60kVA (or 40kVA with N+1 fault tolerance)
Technical Specs
P/N: SV20KS1P3B Key Specs
Item
20KVA SMART ONLINE 3-PHASE UPS SMALL FRAME MODULAR 3 BATTERIES
OEM
Tripp Lite
OEM #
SV20KS1P3B
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Batteries Qty
3
Battery
Expandable
Dimensions (WxDxH)
23.6 in x 43.3 in x 58.1 in
Input Connectors
Hardwire
Input Voltage
AC 120/127/208/220 V
Input Wiring
3-phase WYE (star)
Networking
RS-232
Output Voltage
AC 120/127/208/220 V
Output connectors
Hardwire
Power Capacity
18 kW / 20000 VA
Remote Management Protocol
SNMP, Telnet, SSH
Run Time (Up To)
21.5 min
Weight
1360.99 lbs
