UPS 1500VA 1200W SMART ONLINE TOWER 100V-120V USB DB9 SNMP RT
UPS 1500VA 1200W SMART ONLINE TOWER 100V-120V USB DB9 SNMP RT
Product Overview
Tripp Lite's SmartOnline SU1500XL on-line, double conversion UPS protects critical server, networking or telecommunications equipment from blackouts, brownouts, voltage fluctuations and surges. Large-capacity 1.5kVA/1200W UPS continuously converts incoming AC to DC, then back to perfect sine wave AC output at 120V AC (+/-2%). Removes harmonic distortion, fast electrical impulses, frequency fluctuations and other hard-to-solve power problems not addressed by other UPS systems. True sine wave output and zero transfer time provides guaranteed compatibility with all equipment types. Highly efficient operation in optional economy mode setting, saving BTU heat output and energy costs. Includes 6 UPS-supported outlets. 2 load banks, each with 3 outlets, can be independently controlled via a software interface to selectively reboot remote equipment or automatically shed less critical loads to extend battery runtime for the most critical equipment. Battery backup time can be extended with the addition of multiple external battery packs. Includes slot for network management card options, plus DB9 enhanced serial monitoring port for unattended shutdown, remote control and monitoring of UPS system and power data. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Tripp Lite's PowerAlert UPS Management Software is available via free download. Compatible with Tripp Lite's Watchdog Service Monitoring/Rebooting Software. Attractive all-black upright tower format. $250,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only)
- Package Includes:
• SU1500XL UPS System
• USB, DB9 and EPO cabling
• Owner's manual with warranty information
Technical Specs
P/N: SU1500XL Key Specs
Item
UPS 1500VA 1200W SMART ONLINE TOWER 100V-120V USB DB9 SNMP RT
OEM
Tripp Lite
OEM #
SU1500XL
Returnable
No
Warranty
Backup Time (Half/Full Load)
14 min/4.5 min
Battery
Lead acid expandable
Battery Form Factor
Internal
Dimensions (WxDxH)
9.1 in x 19.5 in x 10.2 in
Input Connectors
1 x power NEMA 5-15
Input Voltage
AC 100/110/120 V
Input Voltage - UPS Systems
120V AC
Medical Grade
No
Number of Outlets
6
Outlet Type - UPS Systems
UPS/Surge
Output Voltage
AC 100/110/120 V ± 2%
Output Voltage - UPS Systems
100V AC, 110V AC, 120V AC
Output connectors
6 x power NEMA 5-15
Power Capacity
1.2 kW / 1500 VA
Product Type
UPS System
Run Time (Up To)
4.5 min at full load
UPS Type
On-Line/Double Conversion
VA Rating - UPS Systems
1.5 kVA
Watts - UPS Systems
1.2 kW
Weight
48.94 lbs
Tripp Lite's SmartOnline SU1500XL on-line, double conversion UPS protects critical server, networking or telecommunications equipment from blackouts, brownouts, voltage fluctuations and surges. Large-capacity 1.5kVA/1200W UPS continuously converts incoming AC to DC, then back to perfect sine wave AC output at 120V AC (+/-2%). Removes harmonic distortion, fast electrical impulses, frequency fluctuations and other hard-to-solve power problems not addressed by other UPS systems. True sine wave output and zero transfer time provides guaranteed compatibility with all equipment types. Highly efficient operation in optional economy mode setting, saving BTU heat output and energy costs. Includes 6 UPS-supported outlets. 2 load banks, each with 3 outlets, can be independently controlled via a software interface to selectively reboot remote equipment or automatically shed less critical loads to extend battery runtime for the most critical equipment. Battery backup time can be extended with the addition of multiple external battery packs. Includes slot for network management card options, plus DB9 enhanced serial monitoring port for unattended shutdown, remote control and monitoring of UPS system and power data. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Tripp Lite's PowerAlert UPS Management Software is available via free download. Compatible with Tripp Lite's Watchdog Service Monitoring/Rebooting Software. Attractive all-black upright tower format. $250,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only)
- Package Includes:
• SU1500XL UPS System
• USB, DB9 and EPO cabling
• Owner's manual with warranty information
