OEM#: PDUMH15HVATNew OEM Original Outright
PDU METERED ATS 2/2.4KW 200/240V 10 C13 2 C14 3.6M CORDS 1URM by Tripp Lite
Your price:
$700.19 each $798.00 Savings: $97.81 (12%)
View All
OEM#: PDUMH15HVATPDU METERED ATS 2/2.4KW 200/240V 10 C13 2 C14 3.6M CORDS 1URM by Tripp Lite
New OEM Original Outright
Your price:
$700.19 each
$798.00 Savings: $97.81 (12%)
2 2.4kW Single-Phase ATS/Metered PDU, 200?240V Outlets (10 C13), 2 C14 Inlets, 3.6 m Cords, 1U Rack-Mount, TAA
Asset Information
Lifetime Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDUMH15HVAT 2–2.4kW Single-Phase 200–240V ATS/Metered PDU enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 1U of space in EIA-standard 19-inch racks and features 10 C13 outlets.Dual 3.6-meter input cords with IEC-320 C14 plugs connect to separate primary and secondary single-phase power sources in a nominal voltage range from 200–240V. Plug lock inserts prevent cords from accidental disconnection. The PDUMH15HVAT constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 2–5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.Built-in slot supports the optional SNMPWEBCARD and WEBCARDLX (sold separately), which turn the PDUMH15HVAT into a switched PDU by allowing remote access to the PDU for power monitoring, configuration, outlet control and notifications via web browser, SSH, telnet or SNMP. Digital ammeter monitors total output current. LEDs display outlet on/off status and input power status on primary and secondary inputs.
- Package Includes:
• PDUMH15HVAT TAA-Compliant 2–2.4kW Single-Phase ATS/Metered PDU
• (10) C14 plug lock inserts
• (2) C13 to C14 power cords, 3.6 m (11.8 ft.)
• (2) Mounting brackets, horizontal
• (2) Mounting brackets, vertical
• (6) Screws
• Owner’s manual
Features
- 10 C13 outlets
- Automatic transfer switching within 5 ms
- Digital load meter for real-time output current monitoring
- Mounts in 1U of space in EIA-standard 19 in. racks
- Single-phase IEC-320 C14 input and 200-240V output
Technical Specs
P/N: PDUMH15HVAT Key Specs
Item
PDU METERED ATS 2/2.4KW 200/240V 10 C13 2 C14 3.6M CORDS 1URM
OEM
Tripp Lite
OEM #
PDUMH15HVAT
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Dimensions (WxDxH)
17.3 in x 14.4 in x 1.7 in
Input Connectors
2 x power IEC 60320 C14
Input Voltage
AC 200/208/220/230/240 V
Output Voltage
AC 200/208/220/230/240 V
Output connectors
10 x power IEC 60320 C13
Power Capacity
2.4 kW
Rack Size
19" - 1U
TAA Compliant
TAA Compliant
Weight
10.32 lbs
The PDUMH15HVAT 2–2.4kW Single-Phase 200–240V ATS/Metered PDU enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 1U of space in EIA-standard 19-inch racks and features 10 C13 outlets.Dual 3.6-meter input cords with IEC-320 C14 plugs connect to separate primary and secondary single-phase power sources in a nominal voltage range from 200–240V. Plug lock inserts prevent cords from accidental disconnection. The PDUMH15HVAT constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 2–5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.Built-in slot supports the optional SNMPWEBCARD and WEBCARDLX (sold separately), which turn the PDUMH15HVAT into a switched PDU by allowing remote access to the PDU for power monitoring, configuration, outlet control and notifications via web browser, SSH, telnet or SNMP. Digital ammeter monitors total output current. LEDs display outlet on/off status and input power status on primary and secondary inputs.
