OEM#: PDUMH15ATNETNew OEM Original Outright
POWER STRIP 8 OUTLET by Tripp Lite
Your price:
$1,004.71 each $1,145.00 Savings: $140.29 (12%)
OEM#: PDUMH15ATNETPOWER STRIP 8 OUTLET by Tripp Lite
New OEM Original Outright
Your price:
$1,004.71 each
$1,145.00 Savings: $140.29 (12%)
1.4kW Single-Phase ATS / Switched PDU with LX Platform Interface, 120V outlets (8 5-15R), 2 5-15P 120V 12ft Inputs, 1U Rack-Mount, TAA
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether, the ATS will switch over to the secondary power source until the primary input is restored and stable. The built-in Java-free HTML5-based LX Platform interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Switched PDU features include individually controllable output receptacles. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources, regardless of phase angle, to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment, the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits, backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
- Package Includes:
• ATS / Switched PDU with attached 5-15P input power cord
• Detachable C13 to NEMA 5-15P 12 ft / 3.6m secondary input cord
• Installable 1U mounting brackets
• User manuals with warranty information
Features
- 1U horizontal rackmount, 2 NEMA 5-15P inputs, 8 NEMA 5-15R outlets
- Built-in Java-free LX Platform interface for 24/7 remote access
- Enables redundant A/B power option for single-corded network devices
- Federal Trade Agreements Act / TAA Compliant for GSA Schedule purchases
- Individually switched outlets, Two digit visual current meter
- Separate primary & secondary inputs connect to any two compatible power sources
- Single phase 15A 120V Auto Transfer Switch / ATS PDU
Technical Specs
P/N: PDUMH15ATNET Key Specs
Item
POWER STRIP 8 OUTLET
OEM
Tripp Lite
OEM #
PDUMH15ATNET
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
AC Input
NEMA 5-15P (2)
AC Outlets
8
AC Output
NEMA 5-15R
Amperage Rating
15 A
Cord Length
12 ft
Dimensions (WxDxH)
17.5 in x 14.5 in x 1.7 in
Housing Material
Steel
Input Connectors
2 x power NEMA 5-15
Input Voltage
AC 120 V
Mounting Type
Rack; Horizontal
Networking
Ethernet 10/100
Output Voltage
AC 120 V
Output connectors
8 x power NEMA 5-15/20
Overload Protection
No
Power Capacity
1.4 kW / 1800 VA
Rack Size
1U
Region
North America
Remote Management Protocol
SNMP, Telnet, HTTP
Voltage Rating
120 V
Weight
11.02 lbs
Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether, the ATS will switch over to the secondary power source until the primary input is restored and stable. The built-in Java-free HTML5-based LX Platform interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Switched PDU features include individually controllable output receptacles. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources, regardless of phase angle, to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment, the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits, backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
