OEM#: PDU330AT6L2130New OEM Original Outright
POWER DISTRIBUTION UNITS by Tripp Lite
Your price:
$2,873.79 each $3,363.00 Savings: $489.21 (15%)
View All
OEM#: PDU330AT6L2130POWER DISTRIBUTION UNITS by Tripp Lite
New OEM Original Outright
Your price:
$2,873.79 each
$3,363.00 Savings: $489.21 (15%)
8.6kW 3-Phase 208V Monitored Rack ATS, 1U, 2 L21-30P, 6 ft. Cords, (Vertical PDU also required, Sold Separately)
Asset Information
1-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The PDU330AT6L2130 8.6kW 3-Phase 208V ATS/Monitored PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Working in tandem with a required 0U vertical outlet accessory (sold separately; choose from PDU3V20D354, PDU3V20D354A or PDU3V20D354B), the 1U PDU330AT6L2130 is ideal for data centers and server rooms. Tripp Lite’s breakthrough 3-phase rack ATS (U.S. Patent 9,467,006) providesrapid coordination of unsynchronized phases without dropping loads and operateswith the high efficiency and reliability required for data center applications.Dual 6-foot input cords with L21-30P plugs connect to separate primary and secondary 3-phase power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1–6 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption. Built-in Ethernet network interface allows remote access to the PDU for power monitoring, configuration, control and notifications via web browser, SSH, telnet or SNMP. Provides real-time load/current data with billing-grade accuracy (+/- 1 percent). Tiered access privileges allow both an administrator and a guest to log in. Automated alerts help prevent accidental overloads, power loss and downtime. Digital LED display indicates power availability, voltage, source A/B input status, output load and power factor, as well as temperature and humidity conditions with the optional ENVIROSENSE module (sold separately).
- Package Includes:
• PDU330AT6L2130 8.6kW 3-Phase 208V ATS/Monitored PDU
• Rack installation brackets
• Configuration cable
• Owner’s manual
Features
- 3-phase L21-30P input and single-phase 208V output
- Automatic transfer switching within 1-6 ms
- Digital LED display for real-time status monitoring
- Ethernet network interface for remote access
- Patented ATS technology
- Requires Tripp Lite 0U outlet accessory (sold separately)
Technical Specs
P/N: PDU330AT6L2130 Key Specs
Item
POWER DISTRIBUTION UNITS
OEM
Tripp Lite
OEM #
PDU330AT6L2130
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Amperage Rating
13.9 A
Connector Type
NEMA L21-30P
Cord Length
6 ft
Dimensions (WxDxH)
16.9 in x 26 in x 1.7 in
Frequency Rating
50 to 60 Hz
Input Connectors
2 x power NEMA L21-30
Input Current
24 A
Input Voltage
AC 208 V
Input Wiring
3-phase
Networking
Ethernet
Number of Phases
4
Output Voltage
AC 208 V
Overload Protection
Yes
Power Capacity
8.6 kW
Rack Size
19" - 1U
Receptacles Type
C13/C19
Remote Management Protocol
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Voltage Rating
208 V
Weight
26.9 lbs
