OEM#: IS1000HGNew OEM Original Outright
120V 1000W NEMA 5-15P - 5-15R HOSPITAL GRADE ISOLATION TRANSFORMER - WHITE by Tripp Lite
Your price:
$691.69 each $915.20 Savings: $223.51 (24%)
OEM#: IS1000HG120V 1000W NEMA 5-15P - 5-15R HOSPITAL GRADE ISOLATION TRANSFORMER - WHITE by Tripp Lite
New OEM Original Outright
Your price:
$691.69 each
$915.20 Savings: $223.51 (24%)
Isolator Series 120V 1000W UL 60601-1 Medical-Grade Isolation Transformer with 4 Hospital-Grade Outlets
Asset Information
2-Year Limited Warranty
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Isolator Series UL 60601-1 Listed Medical-Grade Isolation Transformers offer line isolation and continuous noise filtering. An internal low-impedance isolation transformer component offers 100% isolation from the input AC line. Full UL 60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator medical-grade transformers ideal for protecting sensitive electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the Isolator and connected equipment to levels less than 100 microamps. Removes EMI/RFI noise, utility switching transients and harmonics generated by other on-site loads. Reduces impact of utility- or lightning-related surge conditions. Transformer filtering provides continuous common-mode noise rejection with no wearable parts. Reduces 6000V IEEE587 Category A & B ring wave and combination wave test surges to only 0.5V common mode. Includes four widely spaced NEMA 5-15R hospital-grade output receptacles, 10-foot power cord, hospital-grade input plug, circuit breaker overload protection, lighted power switch and rugged all-metal housing. Ships ready for placement in any industrial, medical, office or network environment. PLUG/OUTLETS: Input - NEMA 5-15P Hospital Grade; Output - 4 NEMA 5-15R Hospital Grade ELECTRICAL: 120V AC, 60 Hz, 8.3A (requires NEMA 5-15R wall receptacle).
- Package Includes:
• IS1000HG Isolation Transformer
• Instruction manual with warranty information
Features
- Complete line isolation andnoise filtering
- Floating AC output prevents noise coupling
- Hospital-grade plug and receptacles
- Lowers cumulative leakage current of connected equipment to under 100
- TAA-compliant
Technical Specs
P/N: IS1000HG Key Specs
Item
120V 1000W NEMA 5-15P - 5-15R HOSPITAL GRADE ISOLATION TRANSFORMER - WHITE
OEM
Tripp Lite
OEM #
IS1000HG
Condition
New OEM Original
Returnable
No
Warranty
Other (See Notes)
Certifications
UL60601-1
Color
White
Connector
5-15P
Connector (Second End)
(4) 5-15R
Cooling Method
Convection
Cord Length
10 FT
Dimensions (WxDxH)
7.2 in x 10.5 in x 7.8 in
Efficiency
0.96
Form Factors Supported
Tower
Frequency
60 HZ
Input Connectors
1 x power NEMA 5-15
Input Voltage
AC 120 V
Leakage Current
< 100 Microamps
Output Voltage
AC 120 V
Output connectors
4 x power NEMA 5-15
Power Capacity
1000 Watt
Volts
120 V
Watts
1000 W
Weight
57.98 lbs
Isolator Series UL 60601-1 Listed Medical-Grade Isolation Transformers offer line isolation and continuous noise filtering. An internal low-impedance isolation transformer component offers 100% isolation from the input AC line. Full UL 60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator medical-grade transformers ideal for protecting sensitive electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the Isolator and connected equipment to levels less than 100 microamps. Removes EMI/RFI noise, utility switching transients and harmonics generated by other on-site loads. Reduces impact of utility- or lightning-related surge conditions. Transformer filtering provides continuous common-mode noise rejection with no wearable parts. Reduces 6000V IEEE587 Category A & B ring wave and combination wave test surges to only 0.5V common mode. Includes four widely spaced NEMA 5-15R hospital-grade output receptacles, 10-foot power cord, hospital-grade input plug, circuit breaker overload protection, lighted power switch and rugged all-metal housing. Ships ready for placement in any industrial, medical, office or network environment. PLUG/OUTLETS: Input - NEMA 5-15P Hospital Grade; Output - 4 NEMA 5-15R Hospital Grade ELECTRICAL: 120V AC, 60 Hz, 8.3A (requires NEMA 5-15R wall receptacle).
- Package Includes:
• IS1000HG Isolation Transformer
• Instruction manual with warranty information
Product Overview
Isolator Series UL 60601-1 Listed Medical-Grade Isolation Transformers offer line isolation and continuous noise filtering. An internal low-impedance isolation transformer component offers 100% isolation from the input AC line. Full UL 60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator medical-grade transformers ideal for protecting sensitive electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the Isolator and connected equipment to levels less than 100 microamps. Removes EMI/RFI noise, utility switching transients and harmonics generated by other on-site loads. Reduces impact of utility- or lightning-related surge conditions. Transformer filtering provides continuous common-mode noise rejection with no wearable parts. Reduces 6000V IEEE587 Category A & B ring wave and combination wave test surges to only 0.5V common mode. Includes four widely spaced NEMA 5-15R hospital-grade output receptacles, 10-foot power cord, hospital-grade input plug, circuit breaker overload protection, lighted power switch and rugged all-metal housing. Ships ready for placement in any industrial, medical, office or network environment. PLUG/OUTLETS: Input - NEMA 5-15P Hospital Grade; Output - 4 NEMA 5-15R Hospital Grade ELECTRICAL: 120V AC, 60 Hz, 8.3A (requires NEMA 5-15R wall receptacle).
- Package Includes:
• IS1000HG Isolation Transformer
• Instruction manual with warranty information
Features
- Complete line isolation andnoise filtering
- Floating AC output prevents noise coupling
- Hospital-grade plug and receptacles
- Lowers cumulative leakage current of connected equipment to under 100
- TAA-compliant
