OEM#: B140-004New OEM Original Outright

4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER by Tripp Lite

Your price:
$352.36 eachShip date will be provided after ordering
4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER by Tripp Lite
4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER by Tripp Lite
4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER by Tripp Lite

OEM#: B140-004
4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER by Tripp Lite

New OEM Original Outright
Your price:
$352.36 each

4-Port DVI over Cat5/Cat6 Extender Splitter, Video Transmitter, 1920x1080 at 60Hz, Up to 200-ft., TAA

Ship date will be provided after ordering
Asset Information

1-Year Limited Warranty

Product Overview

The B140-004 transmits a DVI-D Single-Link signal to four monitors up to 200 ft. away using a single Cat5e/6 patch cable. To achieve maximum distance and resolution, use 24AWG Solid Wire Cat5e/6 cable (Tripp Lite's N202-Series). An additional DVI port is provided for the connection of a local monitor. This local DVI port can also be used to daisychain up to 3 units together, allowing for the connection of up to 13 monitors (12 remote, 1 local). Mounting hardware is included that allows the unit to be rackmounted, wallmounted or pole mounted. In addition, up to three units can be mounted in 1U of rack space using a Tripp Lite B132-004-RB 19" rackmount bracket. The B140-004 is compatible with all operating systems, and is plug and play, with no software or drivers required. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.Installation is simple. Connect the B140-004 transmitter to a DVI source using a Tripp Lite P561-Series DVI cable (not included). Connect a Tripp Lite B140-series receiver (not included) to each display using a Tripp Lite P561-Series DVI cable (not included). Finally, each remote receiver is connected to an RJ45 port on the B140-004 using a single Cat5e/6 cable.For longer extension distances, use a B140-1A0 active receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 150 ft., or a 1024 x 768 @ 60Hz signal up to 200 ft..For shorter extension distances, use a B140-1P0 passive receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 50 ft., or a 1024 x 768 @ 60Hz signal up to 100 ft..Further expand the range and number of monitors by using a B140-110 repeater unit. Add up to four remote units (three repeaters and one active receiver) to each channel of the B140-004, for a total of 4 displays per channel. (An active receiver should be the last unit in a channel) A 1920 x 1080 @ 60Hz signal can be extended up to 125 ft. from each repeater to the next unit in the channel, or a 1024 x 768 @ 60Hz signal can be extended up to 175 ft.

    System Requirements:
    • For international use, a power supply with the appropriate plug type must be purchased separately.


    Package Includes:

    • B140-004 DVI Over Cat5 Extender/Splitter, 4-Port Local Transmitter Unit
    • 1 ft. DVI daisychain cable
    • Mounting hardware
    • External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
    • Owner's Manual

Features
  • Manufacturer: Tripp Lite
  • Condition: New OEM Original
  • Purchase Type: Outright
  • Warranty: Other (See Notes)
  • Returnable: No
  • Can further expand the range and number of monitors by adding B140-110 repeaters
  • Compatible with all operating systems
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
  • For longer distances - Use a B140-1A0 active receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 150 ft., or a 1024 x 768 @ 60Hz signal up to 200 ft.
  • For shorter distances - Use a B140-1P0 passive receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 50 ft., or a 1024 x 768 @ 60Hz signal up to 100 ft.
  • Plug and play, no software or drivers required
  • Supports DVI-D Single-Link video resolutions up to 1920 x 1080 @ 60Hz
  • Use 24AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite's N202-Series, to achieve maximum distance and resolution
Equivalents
  • B140-004: Eaton Corporation
Technical Specs

P/N: B140-004 Key Specs

Item
4-PORT DVI OVER CAT5 CAT6 EXTENDER SPLITTER VIDEO TRANSMITTER
OEM
Tripp Lite
OEM #
B140-004
Condition
New OEM Original
Returnable
No
Connection Type
4 Port DVI-I Dual-Link Female x DVI-I Female
Current Rating
0.5 A
Dimensions (WxDxH)
5 in x 4 in x 1.1 in
Form Factor
External
Frequency
50/60 HZ
Max Transfer Distance
200 ft
Ports Qty
4
Power
AC 120/230 V
Resolution
1920 x 1080 Pixel
Standards
GSA, TAA
Voltage Rating
100 to 240 VAC
