OEM#: B132-008A-2New OEM Original Outright
8PT VGA/AUDIO EXTENDER/SPLITTR by Tripp Lite
Your price:
$222.93 each $241.00 Savings: $18.07 (7%)
View All
OEM#: B132-008A-28PT VGA/AUDIO EXTENDER/SPLITTR by Tripp Lite
New OEM Original Outright
Your price:
$222.93 each
$241.00 Savings: $18.07 (7%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The B132-008A-2 8-Port VGA + Audio over Cat5/Cat6 Extender/Splitter works with a B132-100A or B132-100A-WP-1 remote receiver to split a VGA audio/video signal into nine separate signals—one local and eight remote. It’s ideal for digital signs, trade shows and other applications where the video source is located farther than conventional cables allow or that require multiple displays connected to one source.The B132-008A-2 uses VGA cable (such as Tripp Lite’s P504-Series) to connect to the source and displays and Cat5e/6 cable to transmit to the remote receivers. For best results, use 24 AWG solid-wire N022-01K-GY (Cat5e) or N222-01K-GY (Cat6) cable.When used with Tripp Lite’s B132-Series active remote receivers, the B132-008A-2 can extend a 1920 x 1440 (60 Hz) signal up to 500 feet and a 1024 x 768 (60 Hz) signal up to 1,000 feet. By daisy-chaining up to six units, one audio/video source can transmit to as many as 49 displays—48 remote and one local. Add up to three B132-110A remote repeaters to each channel to fully extend the signal range or add more displays. You can extend a 1920 x 1440 (60 Hz) signal up to 500 feet or a 1024 x 768 (60 Hz) signal up to 1,000 feet from the first repeater in the chain to the last receiver.The B132-008A-2 also delivers high-quality audio and copies EDID information from a connected display to ensure optimal compatibility. Easy to set up with no software or drivers to install. Mounts to a wall, rack or pole using the included hardware.
- Package Includes:
• B132-008A-2 8-Port VGA + Audio over Cat5/6 Extender Splitter
• External power supply (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
• VGA + audio daisy-chain cable, 1 ft.
• Mounting hardware
• Owner’s manual
Features
- Daisy-chain up to 6 units to extend signal to 49 displays
- Extends 1024 x 768 @ 60 Hz audio/video signal up to 1,000 ft.
- Extends 1920 x 1440 @ 60 Hz audio/video signal up to 500 ft.
- Plug and play-no software or drivers to install
- Requires Tripp Lite remote receivers (sold separately)
Technical Specs
P/N: B132-008A-2 Key Specs
Item
8PT VGA/AUDIO EXTENDER/SPLITTR
OEM
Tripp Lite
OEM #
B132-008A-2
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Dimensions (W x D x H)
9.3 in x 3.9 in x 1.2 in
Form Factor
External
Maximum Transfer Distance
1000 ft
Port Quantity
8
Power
AC 120/230 V
Weight
23.98 oz
The B132-008A-2 8-Port VGA + Audio over Cat5/Cat6 Extender/Splitter works with a B132-100A or B132-100A-WP-1 remote receiver to split a VGA audio/video signal into nine separate signals—one local and eight remote. It’s ideal for digital signs, trade shows and other applications where the video source is located farther than conventional cables allow or that require multiple displays connected to one source.The B132-008A-2 uses VGA cable (such as Tripp Lite’s P504-Series) to connect to the source and displays and Cat5e/6 cable to transmit to the remote receivers. For best results, use 24 AWG solid-wire N022-01K-GY (Cat5e) or N222-01K-GY (Cat6) cable.When used with Tripp Lite’s B132-Series active remote receivers, the B132-008A-2 can extend a 1920 x 1440 (60 Hz) signal up to 500 feet and a 1024 x 768 (60 Hz) signal up to 1,000 feet. By daisy-chaining up to six units, one audio/video source can transmit to as many as 49 displays—48 remote and one local. Add up to three B132-110A remote repeaters to each channel to fully extend the signal range or add more displays. You can extend a 1920 x 1440 (60 Hz) signal up to 500 feet or a 1024 x 768 (60 Hz) signal up to 1,000 feet from the first repeater in the chain to the last receiver.The B132-008A-2 also delivers high-quality audio and copies EDID information from a connected display to ensure optimal compatibility. Easy to set up with no software or drivers to install. Mounts to a wall, rack or pole using the included hardware.
- Package Includes:
• B132-008A-2 8-Port VGA + Audio over Cat5/6 Extender Splitter
• External power supply (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
• VGA + audio daisy-chain cable, 1 ft.
• Mounting hardware
• Owner’s manual
