OEM#: B020-U08-19-IP

RACK CONSOLE KVM SWITCH 8-PORT W/ 19" LCD BUILT-IN IP by Tripp Lite

Tripp Lite’s B020-U08-19-IP KVM Switch gives you a rack-mountable keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. From across the room, down the street or halfway around the globe, the B020-U08-19-IP can be accessed from any computer on the LAN, WAN or Internet. Easy to install and use, it’s the optimal solution for controlling up to 8 computers/servers. Increase the number of connected computers up to 256 by daisy-chaining up to 31 B022-U08 KVM switches.The B020-U08-19-IP has a built-in 19” LCD screen that supports video resolutions up to 1280 x 1024 @ 75Hz, with remote monitor resolutions up to 1600 x 1200 @ 60Hz. You can switch easily between the 8 ports using on-console push buttons, an on-screen display (OSD) or keyboard hot key commands. Up to 64 users can be authorized with any combination of admins and users. Multi-level security enhances protection of data and equipment.This switch controls PS/2 or USB computers/servers using a P778-Series Combo KVM Cable Kit (two cable kits are included). A USB port on the front of the keyboard lets you connect an external mouse, plus an external USB 1.1 port means you can add a peripheral that can be shared across all connected servers. When not in use, the B020-U08-19-IP stores neatly in a rack drawer and pulls out when needed. This KVM console is compatible with all major operating systems. Heavy-duty steel housing stands up to frequent use.

System Requirements:
• Servers being connected to the KVM must have a HD15 port, and a USB port or PS/2 Keyboard/Mouse ports; a P778-Series combo KVM cable kit is required for each connected computer
• Computers that access the KVM remotely should have at least a Pentium III, 1GHz processor
• If remote computer is accessing the switch with Windows Client, DirectX 7.0 or higher is needed; if accessing the switch with Java Client, Sun’s Java 2 (1.4.2 or higher) runtime environment must be installed
• A network transfer speed of 128Kbps or higher is recommended
• Supports Internet Explorer, Firefox, Mozilla, Safari, Chrome, Opera and Netscape web browsers
• Compatible with all major operating systems
• Power consumption: 120V, 60Hz, 33.5W; 230V, 50Hz, 34W

Package Includes:
• B020-U08-19-IP 8-Port console KVM switch with 19” LCD and built-in IP access
• (x2) P778-Series 6 ft. USB/PS2 combo KVM Cable Kits
• USB/PS2 combo external console Cable Kit
• Grounding wire
• RJ11 to DB9 firmware upgrade cable
• Rackmount hardware
• C13 to 5-15P power cord
• CD with owner’s manual, quick start guide, and device files

Tripp Lite’s B020-U08-19-IP KVM Switch gives you a rack-mountable keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. From across the room, down the street or halfway around the globe, the B020-U08-19-IP can be accessed from any computer on the LAN, WAN or Internet. Easy to install and use, it’s the optimal solution for controlling up to 8 computers/servers. Increase the number of connected computers up to 256 by daisy-chaining up to 31 B022-U08 KVM switches.The B020-U08-19-IP has a built-in 19” LCD screen that supports video resolutions up to 1280 x 1024 @ 75Hz, with remote monitor resolutions up to 1600 x 1200 @ 60Hz. You can switch easily between the 8 ports using on-console push buttons, an on-screen display (OSD) or keyboard hot key commands. Up to 64 users can be authorized with any combination of admins and users. Multi-level security enhances protection of data and equipment.This switch controls PS/2 or USB computers/servers using a P778-Series Combo KVM Cable Kit (two cable kits are included). A USB port on the front of the keyboard lets you connect an external mouse, plus an external USB 1.1 port means you can add a peripheral that can be shared across all connected servers. When not in use, the B020-U08-19-IP stores neatly in a rack drawer and pulls out when needed. This KVM console is compatible with all major operating systems. Heavy-duty steel housing stands up to frequent use.

System Requirements:
• Servers being connected to the KVM must have a HD15 port, and a USB port or PS/2 Keyboard/Mouse ports; a P778-Series combo KVM cable kit is required for each connected computer
• Computers that access the KVM remotely should have at least a Pentium III, 1GHz processor
• If remote computer is accessing the switch with Windows Client, DirectX 7.0 or higher is needed; if accessing the switch with Java Client, Sun’s Java 2 (1.4.2 or higher) runtime environment must be installed
• A network transfer speed of 128Kbps or higher is recommended
• Supports Internet Explorer, Firefox, Mozilla, Safari, Chrome, Opera and Netscape web browsers
• Compatible with all major operating systems
• Power consumption: 120V, 60Hz, 33.5W; 230V, 50Hz, 34W

Package Includes:
• B020-U08-19-IP 8-Port console KVM switch with 19” LCD and built-in IP access
• (x2) P778-Series 6 ft. USB/PS2 combo KVM Cable Kits
• USB/PS2 combo external console Cable Kit
• Grounding wire
• RJ11 to DB9 firmware upgrade cable
• Rackmount hardware
• C13 to 5-15P power cord
• CD with owner’s manual, quick start guide, and device files
