OEM#: M164-56C-XSNew OEM Original Outright

SPEED REDUCER DIRECT DRIVE 56C 11.08 1 by Toledo Gearmotor

Your price:
$891.35 eachReady to ship
HomeToledo GearmotorM16456CXS
SPEED REDUCER DIRECT DRIVE 56C 11.08 1 by Toledo Gearmotor
SPEED REDUCER DIRECT DRIVE 56C 11.08 1 by Toledo Gearmotor

OEM#: M164-56C-XS
SPEED REDUCER DIRECT DRIVE 56C 11.08 1 by Toledo Gearmotor

New OEM Original Outright
Your price:
$891.35 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: M164-56C-XS Key Specs
Item
SPEED REDUCER DIRECT DRIVE 56C 11.08 1
OEM
Toledo Gearmotor
OEM #
M164-56C-XS
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Ball
Bore Dia.
5/8 in
Duty
Class I
Frame
56C
Gear Material
Steel
Gear Type
Spur
Housing Material
Die Cast Aluminum
Input RPM
1,725
Lubrication
Shipped Dry, Recommend Synthetic 75W90
Max. Input HP
1.5 hp
Max. Output Torque
290.0 in-lb
Mounting
Any Position
Nominal Output RPM
157
Nominal Ratio
11.08:1
Number of Stages
2
Output Shaft Dia.
7/8 in
Output Torque @ 1 HP
176 in-lb
Output Torque @ 1.5 HP
255 in-lb
Output Torque @ 1/2 HP
88 in-lb
Output Torque @ 1/3 HP
58 in-lb
Output Torque @ 1/4 HP
44 in-lb
Output Torque @ 3/4 HP
132 in-lb
Overall Length
7 in
Overhung Load
191 lb
Pinion Material
Hardened and Ground Steel
Rotation
Reversible
Seal Type
Double Lip on Input and Output
Shaft Orientation
Parallel
Single/Double Output/Universal
Single Output
Speed Reducer Type
Direct Drive, Inline
