OEM#: TTW-12ERA1/J5UNew OEM Original Outright
THROUGH THE WALL AIR CONDITIONER 12,000 BTU, COOL WITH HEAT, 208/230V by Tcl Home Appl. (Hk) Co.
Your price:
$774.54 each
OEM#: TTW-12ERA1/J5UTHROUGH THE WALL AIR CONDITIONER 12,000 BTU, COOL WITH HEAT, 208/230V by Tcl Home Appl. (Hk) Co.
New OEM Original Outright
Your price:
$774.54 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: TTW-12ERA1/J5U Key Specs
Item
THROUGH THE WALL AIR CONDITIONER 12,000 BTU, COOL WITH HEAT, 208/230V
OEM
Tcl Home Appl. (Hk) Co.
OEM #
TTW-12ERA1/J5U
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amp Circuit
20
Amps Cooling
5.9
Amps Heating
15
Approvals Or Certifications
UL, cUL Listed
Assembly
Assembled
Btu Cooling
12,000
Btu Heating
10,600
Cfm High
276
Cfm Low
241
Cfm Medium
259
Color Finish
White
Compressor Lra
29
Compressor Rla
4
Compressor Type
Rotary
Controls
Electronic
Country of Origin
China
Coverage (sq ft)
550
Decibels (Dba)
60
Dehumidification Pints / Hour
3.5
Depth Inches
20-1/4
Energy Efficiency Rating (Eer)
9.7
Energy Star Certified
No
Height Inches
14-1/2
Hertz (Hz)
60
Maximum Wall Thickness Inches
16-3/4
Phase
1
Power Cord Length Feet
4.8
Power Cord Type
LCDI Type Plug
Refrigerant
R410A
Refrigerant Charge Oz
20.1
Remote Control
Included
Rpm
1,450
Speeds
3
Temperature Range Cooling (F)
61 to 88
Temperature Range Heating (F)
61 to 88
Voltage
208 / 230
Wall Cut-Out Height Inches
15-3/4
Wall Cut-Out Width Inches
26
Watts Cooling
1,230
Watts Heating
3,450
Weight Lbs
76.06
Width Inches
24-3/16
