OEM#: 10SCH158New OEM Original Outright

SLEEVE CPLING SPACER HUB FIXEDBORE1-5/8 by TB Wood's

Your price:
$321.12 eachReady to ship
HomeTB Wood's10SCH158
SLEEVE CPLING SPACER HUB FIXEDBORE1-5/8 by TB Wood's
SLEEVE CPLING SPACER HUB FIXEDBORE1-5/8 by TB Wood's

OEM#: 10SCH158
SLEEVE CPLING SPACER HUB FIXEDBORE1-5/8 by TB Wood's

New OEM Original Outright
Your price:
$321.12 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 10SCH158 Key Specs
Item
SLEEVE CPLING SPACER HUB FIXEDBORE1-5/8
OEM
TB Wood's
OEM #
10SCH158
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore Dia.
1 5/8 in
Bore Type - Couplings
Fixed Bore
Bushing Required
None
Flange Type - Sleeve Couplings
SC
Height (In.)
2.344 in
Hub Dia. (In.)
2.344 in
Ideal For
Applications In Motors, Pumps, Compressors, Blowers, Mixers and Conveyors
Item - Sleeve Coupling Flanges
Sleeve Coupling Spacer Hub
Keyway Size Type
3/8 in x 3/16 in
Length through Bore (In.)
2.344 in
Material of Construction
Cast Iron
Max. Angular Misalignment
0.25 Degrees For Hytrel Sleeves, 1 Degrees For EPDM & Neoprene Sleeves
Max. RPM
3,600 RPM
Outside Dia.
2.344 in
Setscrew Location
One over the Keyway
Size - Sleeve Couplings
10
Width (In.)
2.344 in
