OEM#: ST121HDBTPWNew OEM Original Outright

100M L CABLE BLACK STEEL CAT5E HDBASET EXTENDER KIT WITH (1) HDMI EXTENDER/(1) HDMI RECEIVER/(4) MOUNTING BRACKETS/(2) FOOT PAD SET by StarTech.com Ltd.

Your price:
$480.06 eachReady to ship
100M L CABLE BLACK STEEL CAT5E HDBASET EXTENDER KIT WITH (1) HDMI EXTENDER/(1) HDMI RECEIVER/(4) MOUNTING BRACKETS/(2) FOOT PAD SET by StarTech.com Ltd.
100M L CABLE BLACK STEEL CAT5E HDBASET EXTENDER KIT WITH (1) HDMI EXTENDER/(1) HDMI RECEIVER/(4) MOUNTING BRACKETS/(2) FOOT PAD SET by StarTech.com Ltd.

OEM#: ST121HDBTPW
100M L CABLE BLACK STEEL CAT5E HDBASET EXTENDER KIT WITH (1) HDMI EXTENDER/(1) HDMI RECEIVER/(4) MOUNTING BRACKETS/(2) FOOT PAD SET by StarTech.com Ltd.

New OEM Original Outright
Your price:
$480.06 each

Extend HDMI up to 330ft (100m) over CAT5/CAT6 cable with Power over Cable to Receiver

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
Product Overview

This HDBaseT extender Kit, extends HDMI up to 330 feet (100 Meters) over a single CAT5e or CAT6 cable. The extender supports Ultra HD and Full HD resolutions (4K / 1080p) with support for 3D and the accompanying 7.1 digital audio. For added versatility, both the transmitter and receiver can be powered by the same single power source using Power Over Cable (POC). The versatility of this video extender makes it an ideal solution for digital signage applications in large buildings such as commercial shopping centers, stadiums, schools, and hospitals.

  • Extend video where power outlets are limited with HDBaseT offering power over cable that powers both the transmitter and receiver using a single power source at either side of the connection
  • Maintains astonishing picture quality up to 115 ft. (35 m) away, with support for UltraHD 4K over non-proprietary CAT5e or CAT6 cabling
  • Also supports HD video resolutions such as 1920x1200 or 1080p at distances up to 330 ft. (100m)
  • Hassle-free, professional installation with included mounting brackets, and full video extension existing infrastructure
  • HDMI transmitter and receiver included
  • Extend HDMI, and Power over Cable all through one Cat5e or CAT6 cable with HDBaseT
  • No software or drivers required
  • Dolby® TrueHD, DTS-HD MA Audio
  • 100m (330ft) maximum Cat5 cable distance
Features
  • Extend video where power outlets are limited with HDBaseT offering power over cable that powers both the transmitter and receiver using a single power source at either side of the connection
  • Maintains astonishing picture quality up to 115 ft. (35 m) away, with support for UltraHD 4K over non-proprietary CAT5e or CAT6 cabling
  • Also supports HD video resolutions such as 1920x1200 or 1080p at distances up to 330 ft. (100m)
  • Hassle-free, professional installation with included mounting brackets, and full video extension existing infrastructure
  • HDMI transmitter and receiver included
  • Extend HDMI, and Power over Cable all through one Cat5e or CAT6 cable with HDBaseT
  • No software or drivers required
  • Dolby® TrueHD, DTS-HD MA Audio
  • 100m (330ft) maximum Cat5 cable distance
Technical Specs
P/N: ST121HDBTPW Key Specs
Item
100M L CABLE BLACK STEEL CAT5E HDBASET EXTENDER KIT WITH (1) HDMI EXTENDER/(1) HDMI RECEIVER/(4) MOUNTING BRACKETS/(2) FOOT PAD SET
OEM
StarTech.com Ltd.
OEM #
ST121HDBTPW
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
AV Input/Output
HDMI
Cabling
Cat5e UTP
Color
Black
Connector (A/B)
1 - RJ-45, 1 - HDMI (19-Pin)
Input Current
0.5A
Input Voltage
100 to 240VAC
LED Indicator
1 - Status (Transmitter), 1 - Status (Receiver)
Length
80mm
Material
Steel
Maximum Cable Length
100m
Maximum Digital Resolution
4096 x 2160 (4K) at 30Hz (35m), 1920 x 1080 (1080p) at 60Hz (100m)
Maximum Distance
100m
Number of Ports
1
Output Current
1.5A
Output Voltage
12VDC
Plug Type
Male
Power Consumption
18W
Power Source
AC Adapter
Relative Humidity
0 to 80% (Non-Condensing)
Temperature Range
0 to 40°C (Operating), -10 to 60°C (Storage)
Type
HDBaseT
