OEM#: QO2175SBNew OEM Original Outright
SURGE PROTECTION DEVICE 120/240VAC 1PH by Square D
Your price:
$246.27 each
OEM#: QO2175SBSURGE PROTECTION DEVICE 120/240VAC 1PH by Square D
New OEM Original Outright
Your price:
$246.27 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: QO2175SB Key Specs
Item
SURGE PROTECTION DEVICE 120/240VAC 1PH
OEM
Square D
OEM #
QO2175SB
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Basic Material
Nonmetallic
Color
Black
Country of Origin
Mexico
Depth
2.6 in
Enclosure Material
Plastic
Enclosure NEMA Rating
1
Filtering
No
Includes
LED Status Indicator
Length
3.7 in
Max Continuing Operating Voltage
150V AC
Max Operating Temperature
149 Degrees F
Max Surge Current per Mode
22.5kA
Max Surge Current per Phase
22.5 kA
Modes of Protection
L-L, L-N
Modular
No
Mounting Location
Internally Mounted
Mounting Style
For QO Load Centers
Nominal Discharge Current
5 kA
Number of Poles
2
Number of Wires
3 Wires
Phase
1
Short Circuit Current Rating
22kA
Standards
CSA 233.1-87, CSA C22.2 No. 8-M1986, NEC Article 285, Type 2, UL 1449, UL Listed
System Connection
Parallel
UL SPD Type
Type 2
Voltage
120/240V AC
Voltage Protection Rating
1500V (L-L), 700V (L-N)
Width
1.5 in
