OEM#: 4B233New OEM Original Outright
ELECTRIC AIR COMPRESSOR 2 HP 1 STAGE by Speedaire
Your price:
$1,383.24 each
OEM#: 4B233ELECTRIC AIR COMPRESSOR 2 HP 1 STAGE by Speedaire
New OEM Original Outright
Your price:
$1,383.24 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4B233 Key Specs
Item
ELECTRIC AIR COMPRESSOR 2 HP 1 STAGE
OEM
Speedaire
OEM #
4B233
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Outlet
1/2 in
ASME Tank
Yes
Amps
15.0/7.5
Compressor Package Type
Base Model
Control
Pressure Switch
Cylinder Material
Cast Iron
Enclosure
NEMA 1
Finish
Powder Coated
Free Air CFM @ Max. Pressure - Air Compressor
4.9
HP - Air Compressor
2.0 hp
Hz
60
Includes
Manual Drain Valve, Motor Starter Not Included, Oil Sight Glass, Pressure Gauge, Pressure Safety Valve
Input Voltage - Air Compressor
120V AC, 240V AC
Item - Air Compressor
Stationary Air Compressor
Lubrication Type - Air compressor
Splash Lubricated
Motor Type
Open Dripproof
Number of Stages - Air Compressor
1
Off Pressure Switch Setting
135 psi
On Pressure Switch Setting
105 psi
Overall Height
52 in
Overall Length
26 1/4 in
Overall Width
19 in
Phase - Electrical
1
Pump Location - Air Compressor
Tank Mounted
Pump Oil Capacity
11.5 oz
Pump RPM
875
Standards
ASME, California Code 462(L)(2), UL/CSA, UL1450
Style - Air Compressor
Simplex
Tank Size - Air Compressor
30 gal
Tank Style - Air Compressor
Vertical
dBA @ 3 Feet
85
