Replaces Sparkle Power Inc. 9680000995Refurbished Outright

240V 180W 1U HIGH SWITCHING POWER SUPPLY

Your price:
$443.24 eachReady to ship
HomeSparkle Power Inc.9680000995
240V 180W 1U HIGH SWITCHING POWER SUPPLY
240V 180W 1U HIGH SWITCHING POWER SUPPLY

Replaces Sparkle Power Inc. 9680000995
240V 180W 1U HIGH SWITCHING POWER SUPPLY

Refurbished Outright
Your price:
$443.24 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

This Flex ATX 180-Watt Medical-Grade Power Supply Unit is designed to meet or exceed the strictest operating requirement for medical systems. It features high efficiency, full range input, Active PFC, 40mm industrial-duty ball bearing cooling fan with chrome fan guard.

AC Input

  • 100-240V, 4A, 50-60Hz
  • Max Output Power 180W

DC Output

  • 3.3V - 16.8A(ORG)
  • 5V - 12.0A(RED)
  • 12V - 12.0A(YEL)
  • 5Vsb - 2.0A(PUR)
  • -12V - 0.8A(BLUE)
  • P.G Signal(GRAY)
  • Ground(BLACK)

Application

  • High Efficiency
  • Low Ripple and Noise
  • Output Over Volts Protection
  • Short Circuit Protection On All Outputs
  • Resettable Power Shut Down
  • Low Noise Design at Full Load
  • 100% Burn-In Under High Ambient Temperature (50°C)
  • Vacuum-Impregnated Transformer
  • MTBF: 100K Hours at 25°C
  • 100% Hi-Pot Tested
  • Line Input Fuse Protection
Technical Specs
P/N: 9680000995 Key Specs
Item
240V 180W 1U HIGH SWITCHING POWER SUPPLY
OEM
Sparkle Power Inc.
OEM #
9680000995
Condition
Refurbished
Returnable
No
Warranty
90 Day
Amps
4 A
Connector
1 x 20 Pin ATX Molex, 1 x 4 Pin ATX Molex
Frequency
50 - 60 Hz
Input Volts
240 V
Power Rating
180 W
Watts
180 W

This Flex ATX 180-Watt Medical-Grade Power Supply Unit is designed to meet or exceed the strictest operating requirement for medical systems. It features high efficiency, full range input, Active PFC, 40mm industrial-duty ball bearing cooling fan with chrome fan guard.

AC Input

  • 100-240V, 4A, 50-60Hz
  • Max Output Power 180W

DC Output

  • 3.3V - 16.8A(ORG)
  • 5V - 12.0A(RED)
  • 12V - 12.0A(YEL)
  • 5Vsb - 2.0A(PUR)
  • -12V - 0.8A(BLUE)
  • P.G Signal(GRAY)
  • Ground(BLACK)

Application

  • High Efficiency
  • Low Ripple and Noise
  • Output Over Volts Protection
  • Short Circuit Protection On All Outputs
  • Resettable Power Shut Down
  • Low Noise Design at Full Load
  • 100% Burn-In Under High Ambient Temperature (50°C)
  • Vacuum-Impregnated Transformer
  • MTBF: 100K Hours at 25°C
  • 100% Hi-Pot Tested
  • Line Input Fuse Protection
