Replaces Sony Electronics UPX898MDTested Outright
SONY UP-D898MD B/W PRINTER
Your price:
$528.85 each $575.00 Savings: $46.15 (8%)
Replaces Sony Electronics UPX898MDSONY UP-D898MD B/W PRINTER
Tested Outright
Your price:
$528.85 each
Asset Information
Part #UP-D898MD
ADD TO LIST
Features
- High print quality
- A7 print size when using 110hg/110s media
- A6 prints in less than two seconds
- Wide PC compatibility
- Quick guide print
- Enhanced operability
- Uses widely available print media
- Ideal for today's advance ultrasound systems
- User-friendly controls on front panel with addition of jog dial
- High resolution of 325 DPI
- User-friendly controls on front panel with addition of JOG DIAL
- Hybrid - accepts both analog and digital signal input
- Compact, space-saving design
- Unique built-in digital capture enables you to store images on a connected USB drive
- High speed printing of approximately 1.9 seconds
- Utilizes existing 110 series media by sony: upp-110s/5, upp-110hd, upp-110hg
Technical Specs
P/N: UPX898MD Key Specs
Item
SONY UP-D898MD B/W PRINTER
OEM
Sony Electronics
OEM #
UPX898MD
Condition
Tested
Returnable
No
Warranty
6 Month
Frequency
50/60Hz
Gradation
8 bits (256 levels) Processing
Input Connector Interface
VIDEO IN (BNC type) NTSC or PAL composite video signals 1.0 Vp-p, 75 ohms
Input Current
1.3 to 0.6A
Input Current (Standby)
1.3A to 0.6A (0.10A to 0.05A)
Interface
Hi-Speed USB (USB 2.0) (x1)
Interface Built-in Image Capture
USB 2.0
Memory (Analog Connection)
10 frames (850 k x 8 bits for one frame)
Memory (Digital Connection)
4096 x 1280 x 8 bit
Operating Condition Humidity
20% to 80% (noncondensing)
Operating Humidity
20 to 80%
Operating Temperature
5 to 40°C
Output Connector Interface
VIDEO OUT (BNC type) Loop-through
Paper Size
Paper width of 110 MM
Picture Area
320 x 100mm
Picture Area (Analog Connection)
SCAN mode: WIDE1, STD: 94 x 73MM (NTSC), 94 x 71MM (PAL), SIDE: 124 x 96MM (NTSC),127 x 96MM (PAL)
Picture Area (Digital Connection)
12 5/8 x 3 7/8in (Max) 320 x 100MM
Picture Elements
4096 x 1280 dots
Picture Memory
4,096 x 1,280 x 8 (bit)
Picture Size (Analog Connection)
720 x 504 (NTSC), 720 x 604 (PAL)
Picture Size (Digital Connection)
4096 x 1280 dots
Power Requirements
AC 100 V to 240 V, 50/60 Hz
Print Technology
Direct Thermal Printing
Print Time
1.9 seconds approximately
Printer Driver (Digital Connection)
Windows XP 32/64 bit, Vista 32/64 bit, Windows 7 32/64 bit, Windows 8 32/64 bit
Printer Driver Software
Microsoft Windows 7 32/64 bit, 8 32/64 bit, 10 32/64 bit
Printing Method
Direct Thermal Printing
Printing Time (High-Speed Mode)
Approx. 1.9 seconds/image (960 x 1,280 dots)
Printing Time (Normal-Speed Mode)
Approx. 3.3 seconds/image (960 x 1,280 dots)
Remote Connector Interface
Stereo Mini Jack
Resolution
325dp
Storage/Transport Humidity
20% to 80%
Storage/Transport Temperature
-20 to 60°C
Thermal Head
325 dp
Type
A6, Digital
Voltage
100 to 240V
Fitments
- OEC Medical Systems (GE Healthcare)
- 9900 ELITE
- Sony Electronics
- UP897MD
- UPX898MD
