Replaces Sony Electronics UPD898MDRefurbished Exchange

A6 ANALOG BLACK AND WHITE THERMAL PRINTER - 3 1/2 IN

Your price:
$438.31 each
$575.00 Savings: $136.69 (24%)
Ready to ship
BUYING OPTIONS:
Refurbished
Exchange ItemExchange Purchase
$438.31 each
Warranty: 120 Day
Refurbished
Outright Purchase
$557.18 each
Warranty: 120 Day
Tested
Outright Purchase
$668.72 each
Warranty: 6 Month
A6 ANALOG BLACK AND WHITE THERMAL PRINTER - 3 1/2 IN
A6 ANALOG BLACK AND WHITE THERMAL PRINTER - 3 1/2 IN

Replaces Sony Electronics UPD898MD
A6 ANALOG BLACK AND WHITE THERMAL PRINTER - 3 1/2 IN

RefurbishedExchange Item Exchange

Goods sold on an "Exchange" basis require that Buyer return a like, repairable item within 15 days (or the seller's specified time frame) in order to receive the price quoted. For full details, see Terms and Conditions.

Your price:
$438.31 each
With ELIGIBLE Exchange Core SHIPPED BACK
Ready to ship
Asset Information

Please specify connector type: coaxial and USB connections

Product Overview

High speed, high quality black & white printing of medical images with a compact space-saving footprint. The UP-D898MD is a compact A6 medical grade black and white digital printer. It’s designed to be integrated into a wide range of compatible medical imaging environments such as digital ultrasound systems, mobile C-arms or cardiac catheterization laboratory. The high quality thermal print engine can produce hard copy prints of still images captured by these systems for use in patient records and referrals. The UP-D898MD is a successor to the popular Sony UP-897 series of medical printers. Redesigned and upgraded, it offers several operational and ergonomic enhancements while retaining the same space-saving footprint and easy integration into medical carts. Usability is further enhanced by an enlarged LCD display panel and joystick for intuitive menu navigation. Capable of delivering high quality black & white prints in under two seconds. Advanced thermal printing technology delivers near-photo quality results using widely available print media. Unique Sony technology allows paper to be cut in two directions—both up and down—as a lower cutter is newly included, along with the conventional upper cutter. This enables flexible printer installation in almost any location as well as smooth printing operations.

  • High print quality
  • A6 prints in less than two seconds
  • Compact, space-saving design
  • Hard copy reference of print settings
  • Wide PC compatibility
  • Quick guide print
  • Dual cutter configuration
  • Enhanced operability
  • Uses widely available print media
  • Compliance with medical standards
Features
  • Zoom function
  • High-speed printing
  • Universal powering system
  • Compact, small footprint design
  • Superior operability
  • Various print modes
  • Detailed sharpness setting
  • Superb print quality and color at approximately 325-DPI resolution
  • Multiple copy function
  • Various printing paper line-ups
Technical Specs
P/N: UPD898MD Key Specs
Item
A6 ANALOG BLACK AND WHITE THERMAL PRINTER - 3 1/2 IN
OEM
Sony Electronics
OEM #
UPD898MD
Condition
Refurbished
Returnable
No
Warranty
120 Day
Dot Density
H: 12.8 dots /MM = 0.078, V: 12.8 dots /MM = 0.078 Square dots
Gradation
8-bit (256 levels) processing
Input current
1.5 A to 0.8 A
Operating Humidity
20% to 80%
Operating Temperature
5 °C to 35 °C (41 °F to 176 °F)
Picture Elements
EIA: 1210 x 490 dots, CCIR: 1210 x 582 dots
Picture Memory
10 frames (800 k x 8 bits for one frame)
Picture Size
When S:STD is selected from SIDE, When S:STD is selected from SIDE, CCIR: 94 x 71 MM, When S:SIDE is selected from SIDE, EIA: 124 x 96 MM, CCIR: 127 x 96 MM
Power requirement
100 to 240 V AC, 50/60 Hz
Printing Speed
Approx. 2 Seconds/ Image
Resolution
325 DPI
Storage/Transportation Humidity
20% to 90%
Storage/Transportation Temperature
-20 °C to 60 °C (-4 °F to 140 °F)
Thermal Head
Thin-film thermal head, 1280 dots
Fitments

High speed, high quality black & white printing of medical images with a compact space-saving footprint. The UP-D898MD is a compact A6 medical grade black and white digital printer. It’s designed to be integrated into a wide range of compatible medical imaging environments such as digital ultrasound systems, mobile C-arms or cardiac catheterization laboratory. The high quality thermal print engine can produce hard copy prints of still images captured by these systems for use in patient records and referrals. The UP-D898MD is a successor to the popular Sony UP-897 series of medical printers. Redesigned and upgraded, it offers several operational and ergonomic enhancements while retaining the same space-saving footprint and easy integration into medical carts. Usability is further enhanced by an enlarged LCD display panel and joystick for intuitive menu navigation. Capable of delivering high quality black & white prints in under two seconds. Advanced thermal printing technology delivers near-photo quality results using widely available print media. Unique Sony technology allows paper to be cut in two directions—both up and down—as a lower cutter is newly included, along with the conventional upper cutter. This enables flexible printer installation in almost any location as well as smooth printing operations.

  • High print quality
  • A6 prints in less than two seconds
  • Compact, space-saving design
  • Hard copy reference of print settings
  • Wide PC compatibility
  • Quick guide print
  • Dual cutter configuration
  • Enhanced operability
  • Uses widely available print media
  • Compliance with medical standards
    • OEC Medical Systems (GE Healthcare)
      • 9900 ELITE
    • Sony Electronics
      • UP897MD
      • UPX898MD
