Replaces Sony Electronics UP-897MDRefurbished Outright

SONY BLACK & WHITE PRINTER, A6

Your price:
$626.43 each
$950.00 Savings: $323.57 (34%)
Ready to ship
HomeSony ElectronicsUP897MD
BUYING OPTIONS:
Refurbished
Outright Purchase
$626.43 each
Warranty: 90 Day
Tested
Outright Purchase
$668.72 each
Warranty: 6 Month
SONY BLACK & WHITE PRINTER, A6
SONY BLACK & WHITE PRINTER, A6

Replaces Sony Electronics UP-897MD
SONY BLACK & WHITE PRINTER, A6

Refurbished Outright
Your price:
$626.43 each
$950.00 Savings: $323.57 (34%)
Ready to ship
Asset Information

Part #UP-D898MD

Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

The UP-897md have a compact and space-saving design can produce a6-size prints with stunning speed. A convenient front LCD display panel and jog dial offer easy maintenance and flexible set up.

Features
  • High print quality
  • A7 print size when using 110hg/110s media
  • A6 prints in less than two seconds
  • Wide PC compatibility
  • Quick guide print
  • Enhanced operability
  • Uses widely available print media
  • Ideal for today's advance ultrasound systems
  • User-friendly controls on front panel with addition of jog dial
  • High resolution of 325 DPI
  • User-friendly controls on front panel with addition of JOG DIAL
  • Hybrid - accepts both analog and digital signal input
  • Compact, space-saving design
  • Unique built-in digital capture enables you to store images on a connected USB drive
  • High speed printing of approximately 1.9 seconds
  • Utilizes existing 110 series media by sony: upp-110s/5, upp-110hd, upp-110hg
Technical Specs
P/N: UP-897MD Key Specs
Item
SONY BLACK & WHITE PRINTER, A6
OEM
Sony Electronics
OEM #
UP-897MD
Condition
Refurbished
Returnable
No
Warranty
90 Day
Frequency
50/60Hz
Gradation
8 bits (256 levels) Processing
Gradations
8 bits (256 levels)
Input Connector Interface
VIDEO IN (BNC type) NTSC or PAL composite video signals 1.0 Vp-p, 75 ohms
Input Current
1.3 to 0.6A
Input Current (Stand By)
1.3A to 0.6A (0.10A to 0.05A)
Interface
Hi-Speed USB (USB 2.0) (x1)
Interface Built-in image capture
USB 2.0
Memory (Analog Connection)
10 frames (850 k x 8 bits for one frame)
Memory (Digital Connection)
4096 x 1280 x 8 bit
Operating Condition Humidity
20% to 80% (noncondensing)
Operating Humidity
20 to 80%
Operating Temperature
5 to 40°C
Output Connector Interface
VIDEO OUT (BNC type) Loop-through
Paper Size
Paper width of 110 MM
Picture Area
320 x 100mm
Picture Area (Analog Connection)
SCAN mode: WIDE1, STD: 94 x 73MM (NTSC), 94 x 71MM (PAL), SIDE: 124 x 96MM (NTSC),127 x 96MM (PAL)
Picture Area (Digital Connection)
12 5/8 x 3 7/8in (Max) 320 x 100MM
Picture Elements
4096 x 1280 dots
Picture Memory
4,096 x 1,280 x 8 (bit)
Picture Size (Analog Connection)
720 x 504 (NTSC), 720 x 604 (PAL)
Picture Size (Digital Connection)
4096 x 1280 dots
Power Requirements
AC 100 V to 240 V, 50/60 Hz
Print Technology
Direct Thermal Printing
Print Time
1.9 seconds approximately
Printer Driver (Digital Connection)
Windows XP 32/64 bit, Vista 32/64 bit, Windows 7 32/64 bit, Windows 8 32/64 bit
Printer Driver Software
Microsoft Windows 7 32/64 bit, 8 32/64 bit, 10 32/64 bit
Printing Method
Direct Thermal Printing
Printing Time High-Speed Mode
Approx. 1.9 seconds/image (960 x 1,280 dots)
Printing Time Normal speed mode
Approx. 3.3 seconds/image (960 x 1,280 dots)
Remote Connector Interface
Stereo Mini Jack
Resolution
325dp
Storage and Transport Humidity
20% to 80%
Storage and Transport Temperature
-20 to 60°C
Thermal Head
325 dp
Type
A6, Digital
Voltage
100 to 240V
Equivalents
Fitments

The UP-897md have a compact and space-saving design can produce a6-size prints with stunning speed. A convenient front LCD display panel and jog dial offer easy maintenance and flexible set up.

  • 5802151: GE Healthcare: Canonical Redirect
  • 066E0112: GE Healthcare: Canonical Redirect
  • 40004R: Mindray North America: Canonical Redirect
  • OEC Medical Systems (GE Healthcare)
    • 9900 ELITE
  • Sony Electronics
    • UP897MD
    • UPX898MD
