OEM#: 505SBNew OEM Original Outright

SPRING CHECK VALVE BRONZE 1-1/2 FNPT by Simmons

Your price:
$148.21 eachReady to ship
HomeSimmons505SB
SPRING CHECK VALVE BRONZE 1-1/2 FNPT by Simmons
SPRING CHECK VALVE BRONZE 1-1/2 FNPT by Simmons

OEM#: 505SB
SPRING CHECK VALVE BRONZE 1-1/2 FNPT by Simmons

New OEM Original Outright
Your price:
$148.21 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 505SB Key Specs
Item
SPRING CHECK VALVE BRONZE 1-1/2 FNPT
OEM
Simmons
OEM #
505SB
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application - Valves
General Purpose
Body Material - Valves
Bronze
Cap to Inlet Center
1-1/2 in
Connection Type - Check Valves
FNPT x FNPT
Country of Origin
USA
Cracking Pressure - Check Valves
1 psi
Flow Design
Single
Hex Size
2-5/8 in
Item - Check Valves
Check Valve
Length
2-5/8 in
Max Steam Pressure - Valves
Not Rated
Max Water Pressure - Valves
400 psi
Maximum Temperature
190 Degrees F
Mechanism and Body Design
Inline Spring
Mounting Orientation - Check Valves
Horizontal, Vertical
Overall Height
4-1/8 in
Pipe or Tube Size - Check Valves
1-1/2 in
Seal Material - Check Valves
Buna-N
Seat Material - Check Valves
Bronze
Spring Material - Check Valves
Stainless Steel
Standards
Certified Lead Free, NSF 61, NSF/ANSI 372
Width
2-5/8 in
