OEM#: 10787117New OEM Original Outright

TRANSDUCER, LINEAR ARRAY FORM FACTOR, 2.9 TO 8.1MHZ FREQUENCY RANGE, 9EC4 SERIES, FOR USE WITH: FOR GENERAL ULTRASOUND by Siemens Medical Solutions

0
HomeSiemens Medical Solutions10787117
TRANSDUCER, LINEAR ARRAY FORM FACTOR, 2.9 TO 8.1MHZ FREQUENCY RANGE, 9EC4 SERIES, FOR USE WITH: FOR GENERAL ULTRASOUND by Siemens Medical Solutions
TRANSDUCER, LINEAR ARRAY FORM FACTOR, 2.9 TO 8.1MHZ FREQUENCY RANGE, 9EC4 SERIES, FOR USE WITH: FOR GENERAL ULTRASOUND by Siemens Medical Solutions

OEM#: 10787117
TRANSDUCER, LINEAR ARRAY FORM FACTOR, 2.9 TO 8.1MHZ FREQUENCY RANGE, 9EC4 SERIES, FOR USE WITH: FOR GENERAL ULTRASOUND by Siemens Medical Solutions

New OEM Original Outright
Ready to ship
Asset Information
ADD TO LIST
Product Overview
Applications:
  • Transvaginal
    • Technical Specs
    P/N: 10787117 Key Specs
    Item
    TRANSDUCER, LINEAR ARRAY FORM FACTOR, 2.9 TO 8.1MHZ FREQUENCY RANGE, 9EC4 SERIES, FOR USE WITH: FOR GENERAL ULTRASOUND
    OEM
    Siemens Medical Solutions
    OEM #
    10787117
    Condition
    New OEM Original
    Returnable
    No
    Warranty
    6 Month
    2D
    Low, Mid, High
    Axial & Lateral Resolution
    0.46 & 0.8 mm
    Azimuth
    30.72 mm
    Bandwidth
    2.9-8.1 MHz
    Cable Length
    2.2 m
    Cable Size
    2.2 m LG
    Color Doppler
    Pen, Mid, Res
    Connection Type
    CoMPAct Pinless
    Connector type
    Compact pinless connector
    Design
    1D, Piezoceramic
    Display Size
    140 mm DP
    Elevation
    6.0 mm
    Field of View
    176 deg
    Field of View / Angle
    176°
    Gesture Detection
    Yes
    Material
    Piezoceramic
    Maximum Display Depth
    140 mm
    Number of Elements
    192
    Physical Footprint
    17.0 x 22.0 mm
    THI
    HLow, HMid, HHigh
    Total Weight
    700 gm
    Type of Array
    Curved
    Fitments
    Applications:
  • Transvaginal
      • Siemens Medical Solutions
        • SEQUOIA
        • SEQUOIA ST
