OEM#: YA2030New OEM Original Outright
PEDESTAL FAN MOTOR 1725 RPM 115 VOLTS 1/3 HP by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$304.70 each
OEM#: YA2030PEDESTAL FAN MOTOR 1725 RPM 115 VOLTS 1/3 HP by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$304.70 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Pedestal Fan Motor 1725 RPM 115 Volts 1/3 HP
- Automatic Reset Overload Protector
- Class B Insulated
- Cushion Base and Special 8.75 Eared Bracket or Flange
- Direct Drive Open
- Double-Sealed Ball Bearings
- Reversible
- Split Phase
- 60°C Ambient Temperature
Technical Specs
P/N: YA2030 Key Specs
Item
PEDESTAL FAN MOTOR 1725 RPM 115 VOLTS 1/3 HP
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
YA2030
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Sleeve
Enclosure Type
Totally Enclosed
Frame
48YZ
Full Load Amps
6
Hertz
60
Hertz (Hz)
60
Horsepower
1/3
Is_Motor
Yes
Motor Rpm 60Hz
1725
Mounting
Yoke
Phase
1
Rated Rpm
1725
Rotation
CCW/CW
Rpm Range
1701-1800
Service Factor
1
Shaft Diameter
0.5
Shaft Length
2
Speeds
1
Voltage
115
Pedestal Fan Motor 1725 RPM 115 Volts 1/3 HP
- Automatic Reset Overload Protector
- Class B Insulated
- Cushion Base and Special 8.75 Eared Bracket or Flange
- Direct Drive Open
- Double-Sealed Ball Bearings
- Reversible
- Split Phase
- 60°C Ambient Temperature
