OEM#: ORM5458BNew OEM Original Outright
CONDENSER FAN MOTOR 1/6TO1/3HP 1075 RPM by Regal Beloit America, Inc. (Century Electric Motors)
Your price:
$144.59 each $149.58 Savings: $4.99 (3%)
OEM#: ORM5458BCONDENSER FAN MOTOR 1/6TO1/3HP 1075 RPM by Regal Beloit America, Inc. (Century Electric Motors)
New OEM Original Outright
Your price:
$144.59 each
$149.58 Savings: $4.99 (3%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: ORM5458B Key Specs
Item
CONDENSER FAN MOTOR 1/6TO1/3HP 1075 RPM
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
ORM5458B
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
5-5/8 in
Bolt Circle Diameter
5 1/7 in
Capacitor Required
2MDV6
Duty
Continuous
Frame
48Y
Full Load Amps
2
HP
1/3 to 1/6
Hz
60
Ins. Class
B
Lead Length
35 1/2 to 38 1/2 in
Length Less Shaft
4-1/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
10-5/8 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
6-1/2 in
Standards
CSA Certified (LR43341), UL Recognized (E46412)
Stud Quantity
4
Stud Size
8-32
Voltage
208-230
